Axial cylindrical roller bearings TN Series
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| K81108 TN |
| K81110 TN |
| K81113 TN |
| K81114 TN |
| K81115 TN |
| K81118 TN |
| K81120 TN |
| K81128 TN |
| K81207 TN |
| K81210 TN |
| K81211 TN |
| K81212 TN |
| K81213 TN |
| K81214 TN |
| K81220 TN |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | I.D. d (mm) | O.D. D (mm) | Width B (mm) | Cage | Internal diameter (mm) | Operating direction | Outer diameter (mm) | Temperature range | Weight (g) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
4.28 € | 1 | 4 Days | 40 | 60 | 6 | Polyamide cage | - | Single direction bearing | - | -20 to +120 °C | 40.0 | ||
5.56 € | 1 | 4 Days | 50 | 70 | 6 | Polyamide cage | - | Single direction bearing | - | -20 to +120 °C | 52.0 | ||
9.42 € | 1 | 4 Days | 65 | 90 | 7.5 | Polyamide cage | - | Single direction bearing | - | -20 to +120 °C | 102.0 | ||
11.23 € | 1 | 4 Days | - | - | 7.5 | - | 70 | one-sided effective | 95 | -20 to +120 degrees | 107.0 | ||
12.85 € | 1 | 4 Days | 75 | 100 | 7.5 | Polyamide cage | - | Single direction bearing | - | -20 to +120 °C | 115.0 | ||
19.30 € | 1 | 4 Days | 90 | 120 | 9 | Polyamide cage | - | Single direction bearing | - | -20 to +120 °C | 147.0 | ||
25.72 € | 1 | 4 Days | 100 | 135 | 11 | Polyamide cage | - | Single direction bearing | - | -20 to +120 °C | 245.0 | ||
50.90 € | 1 | 4 Days | 140 | 180 | 12 | Polyamide cage | - | Single direction bearing | - | -20 to +120 °C | 398.0 | ||
6.30 € | 1 | 4 Days | 35 | 62 | 7.5 | Polyamide cage | - | Single direction bearing | - | -20 to +120 °C | 52.0 | ||
12.15 € | 1 | 4 Days | 50 | 78 | 9 | Polyamide cage | - | Single direction bearing | - | -20 to +120 °C | 97.0 | ||
14.40 € | 1 | 4 Days | 55 | 90 | 11 | Polyamide cage | - | Single direction bearing | - | -20 to +120 °C | 154.0 | ||
16.63 € | 1 | 4 Days | 60 | 95 | 11 | Polyamide cage | - | Single direction bearing | - | -20 to +120 °C | 176.0 | ||
20.24 € | 1 | 4 Days | 65 | 100 | 11 | Polyamide cage | - | Single direction bearing | - | -20 to +120 °C | 187.0 | ||
21.50 € | 1 | 4 Days | 70 | 105 | 11 | Polyamide cage | - | Single direction bearing | - | -20 to +120 °C | 203.0 | ||
59.90 € | 1 | 4 Days | 100 | 150 | 15 | Polyamide cage | - | Single direction bearing | - | -20 to +120 °C | 600.0 |
Loading...
Basic information
| Inner/Outer Ring Material | Steel | Precision (JIS) | Class 0 | Rolling Element Material | Steel |
|---|---|---|---|---|---|
| Angular adjustment | Non-angle adjustable | Product range | Axial cylindrical roller and cage assembly only |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
