Accessory, Mounting Brackets, CQS Series

Accessory, Mounting Brackets, CQS Series

Part number:

Still undefined. 12 possible part numbers found.
Quantity:

Part number list

Number of items
  • 1
    • Part number
    CQS-D012
    CQS-D016
    CQS-D020
    CQS-D025
    CQS-F012
    CQS-F016
    CQS-F020
    CQS-F025
    CQS-L012
    CQS-L016
    CQS-L020
    CQS-L025

    Applicable hole diameter

    (ø)

    Type

    		Minimum order quantity
    12
    Double clevis
    1 pieces
    10
    Double clevis
    1 pieces
    20
    Double clevis
    1 pieces
    25
    Double clevis
    1 pieces
    12
    Flange
    1 pieces
    10
    Flange
    1 pieces
    20
    Flange
    1 pieces
    25
    Flange
    1 pieces
    12
    Foot, requires 2 per cylinder
    1 pieces
    10
    Foot, requires 2 per cylinder
    1 pieces
    20
    Foot, requires 2 per cylinder
    1 pieces
    25
    Foot, requires 2 per cylinder
    1 pieces
    Unit price (excluding VAT)(Unit price including VAT)
    Standard shipping days
    3.55 €
    ( 4.22 € )
    22 working days
    3.90 €
    ( 4.64 € )
    22 working days
    4.27 €
    ( 5.08 € )
    4 working days
    5.05 €
    ( 6.01 € )
    4 working days
    3.55 €
    ( 4.22 € )
    22 working days
    3.90 €
    ( 4.64 € )
    22 working days
    4.27 €
    ( 5.08 € )
    22 working days
    5.05 €
    ( 6.01 € )
    22 working days
    3.55 €
    ( 4.22 € )
    22 working days
    3.90 €
    ( 4.64 € )
    4 working days
    4.32 €
    ( 5.14 € )
    22 working days
    5.05 €
    ( 6.01 € )
    22 working days
  • 1

    • More Information

    Basic information

    · CQS mounting brackets.
    · Type: flange, foot and double clevis.
    · Bore sizes: ø12 to ø25.

    Caution

    • Product images may be representative only. Please see the manufacturer's catalog for shape details.
