PARKER Parkrimp No-Skive Fitting 16F73
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| 16F73-12-12-1P |
| 16F73-20-16-1P |
| 16F73-20-20-1P |
| 16F73-24-20 |
| 16F73-24-24-1P |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Nominal Dia. (mm) | A (mm) | Customs tariff weight (kg) | Thread or tube size | Common name | B (mm) | Hose fitting size | F (mm) | Imperial flange size | E (mm) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
174.26 € | 1 | 5 Days | 19 | 110 | 0.455 | -12 | SFS 45° / 6,000 psi | 62 | -12 | 41 | 3/4 | 26 | ||
250.58 € | 1 | 5 Days | 25 | 129 | 0.682 | -20 | SFS 45° / 6000 psi | 79 | -16 | 54 | 1-1/4 | 32 | ||
317.00 € | 1 | 5 Days | 31 | 163 | 1.222 | -20 | SFS 45° / 6000 psi | 98 | -20 | 54 | 1-1/4 | 38 | ||
395.74 € | 1 | 5 Days | 31 | 163 | 1.39 | -24 | SFS 45° / 6000 psi | 99 | -20 | 63 | 1-1/2 | 38 | ||
467.08 € | 1 | 5 Days | 38 | 178 | 1.661 | -24 | SFS 45° / 6000 psi | 115 | -24 | 64 | 1-1/2 | 44 |
Loading...
Basic information
| Customs tariff weight unit | kg | Steel | Galvanized steel, Cr(VI)-free | Connection group | Flange |
|---|---|---|---|---|---|
| Norm | ISO 12151-3 - E45-S | Description of connection type | ISO 6162-2 - flange - heavy design - 6,000 psi - 45° elbow | Connection type | 6F |
| Fitting series | 73 | Customs tariff item number | 73269098 | Operating pressure Mpa | 42 |
| Customs tariff weight per | 1 | Fitting | Parkrimp fitting | Customs tariff country of origin | DE |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
