PARKER Parkrimp No-Skive Fitting 1J777
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| 1J777-12-12 |
| 1J777-16-16 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Nominal Dia. (mm) | A (mm) | Thread or tube size | W | Thread diameter UNF | B (mm) | Hose fitting size | E (mm) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
108.80 € | 1 | 3 Days | 19 | 111 | -12 | 36 | 1-3/16x12 | 65 | -12 | 21 | ||
150.83 € | 1 | 32 Days | 25 | 133 | -16 | 41 | 1-7/16x12 | 79 | -16 | 24 |
Loading...
Basic information
| Customs tariff weight(kg) | 0 | Customs tariff weight unit | kg | Steel | Galvanized steel, Cr(VI)-free |
|---|---|---|---|---|---|
| Connection group | ORFS | Norm | ISO 12151-1 - SWE 45° - SAE J516 | Common name | ORFS 45° |
| Description of connection type | ORFS with union nut - 45° elbow | Connection type | J7 | Fitting series | 77 |
| Customs tariff item number | 73269098 | Operating pressure Mpa | 41 | Customs tariff weight per | 1 |
| Fitting | Parkrimp fitting | Customs tariff country of origin | DE |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
