PARKER WSV bulkhead elbow
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| WSV06ZLCF |
| WSV08LCF |
| WSV08ZLCF |
| WSV10LCF |
| WSV10ZLCF |
| WSV12LCF |
| WSV12S71 |
| WSV12SCF |
| WSV12ZLCF |
| WSV12ZSCF |
| WSV15LCF |
| WSV15ZLCF |
| WSV16SCF |
| WSV16ZSCF |
| WSV18LCF |
| WSV18ZLCF |
| WSV20SCF |
| WSV22LCF |
| WSV28LCF |
| WSV28ZLCF |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Delivery | PN (bar) | S2 (mm) | D4 | L5 | L7 | Customs tariff weight (kg) | External pipe diameter D1 | L4 | S1 | L2 | L3 | L1 | D3 | Surface | Model series | L6 | Customs tariff item number | S3 | Engineering material | Customs tariff country of origin | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
38.23 € | 1 | 5 Days | EO-2 Complete Fitting Including Nut and Ring | 315 | 17 | 17 | 48 | 42 | 0.083 | 6 | 27 | 12 | 12 | 14 | 19 | 4 | Cr(VI)-free | L | 27 | 73079290 | 14 | Steel | CN | ||
31.17 € | 1 | 5 Days | Complete, including nut and ring | 315 | 19 | 19 | 51 | 42 | 0.104 | 8 | 27 | 12 | 14 | 17 | 21 | 6 | Cr(VI)-free | L | 29 | 73079290 | 17 | Steel | CN | ||
39.80 € | 1 | 5 Days | EO-2 complete fitting including nut and ring | 315 | 19 | 19 | 51 | 42 | 0.105 | 8 | 27 | 12 | 14 | 17 | 21 | 6 | Cr(VI)-free | L | 29 | 73079290 | 17 | Steel | CN | ||
34.46 € | 1 | 5 Days | Complete, including nut and ring | 315 | 22 | 22 | 53 | 43 | 0.126 | 10 | 28 | 14 | 15 | 18 | 22 | 8 | Cr(VI)-free | L | 30 | 73079290 | 19 | Steel | CN | ||
45.71 € | 1 | 5 Days | EO-2 complete fitting including nut and ring | 315 | 22 | 22 | 53 | 43 | 0.133 | 10 | 28 | 14 | 15 | 18 | 22 | 8 | Cr(VI)-free | L | 30 | 73079290 | 19 | Steel | CN | ||
42.32 € | 1 | 5 Days | Complete, including nut and ring | 315 | 24 | 24 | 56 | 44 | 0.172 | 12 | 29 | 17 | 17 | 20 | 24 | 10 | Cr(VI)-free | L | 32 | 73079290 | 22 | Steel | CN | ||
205.95 € | 1 | 5 Days | Complete, including nut and ring | 630 | 27 | 27 | 59 | 47 | 0.26 | 12 | 30.5 | 17 | 21.5 | 21 | 29 | 8 | Stainless steel | S | 38 | 73072290 | 24 | Stainless steel | DE | ||
49.89 € | 1 | 5 Days | Complete, including nut and ring | 630 | 27 | 27 | 59 | 47 | 0.246 | 12 | 30.5 | 17 | 21.5 | 21 | 29 | 8 | Cr(VI)-free | S | 38 | 73079290 | 24 | Steel | CN | ||
53.98 € | 1 | 5 Days | EO-2 complete fitting including nut and ring | 315 | 24 | 24 | 56 | 44 | 0.176 | 12 | 29 | 17 | 17 | 20 | 24 | 10 | Cr(VI)-free | L | 32 | 73079290 | 22 | Steel | CN | ||
62.89 € | 1 | 5 Days | EO-2 complete fitting including nut and ring | 630 | 27 | 27 | 59 | 47 | 0.255 | 12 | 30.5 | 17 | 21.5 | 21 | 29 | 8 | Cr(VI)-free | S | 38 | 73079290 | 24 | Steel | CN | ||
50.62 € | 1 | 5 Days | Complete, including nut and ring | 315 | 30 | 27 | 61 | 46 | 0.269 | 15 | 31 | 19 | 21 | 23 | 28 | 12 | Cr(VI)-free | L | 36 | 73079290 | 27 | Steel | CN | ||
66.20 € | 1 | 5 Days | EO-2 complete fitting including nut and ring | 315 | 30 | 27 | 61 | 46 | 0.276 | 15 | 31 | 19 | 21 | 23 | 28 | 12 | Cr(VI)-free | L | 36 | 73079290 | 27 | Steel | CN | ||
72.12 € | 1 | 5 Days | Complete, including nut and ring | 400 | 32 | 30 | 64 | 50 | 0.399 | 16 | 31.5 | 24 | 24.5 | 24 | 33 | 12 | Cr(VI)-free | S | 43 | 73079290 | 30 | Steel | CN | ||
91.89 € | 1 | 5 Days | EO-2 complete fitting including nut and ring | 400 | 32 | 30 | 64 | 50 | 0.426 | 16 | 31.5 | 24 | 24.5 | 24 | 33 | 12 | Cr(VI)-free | S | 43 | 73079290 | 30 | Steel | CN | ||
72.05 € | 1 | 5 Days | Complete, including nut and ring | 315 | 36 | 32 | 64 | 49 | 0.4 | 18 | 32.5 | 24 | 23.5 | 24 | 31 | 15 | Cr(VI)-free | L | 40 | 73079290 | 32 | Steel | CN | ||
94.91 € | 1 | 5 Days | EO-2 complete fitting including nut and ring | 315 | 36 | 32 | 64 | 49 | 0.39 | 18 | 32.5 | 24 | 23.5 | 24 | 31 | 15 | Cr(VI)-free | L | 40 | 73079290 | 32 | Steel | CN | ||
113.26 € | 1 | 5 Days | Complete, including nut and ring | 400 | 41 | 36 | 74 | 55 | 0.612 | 20 | 33.5 | 27 | 26.5 | 30 | 37 | 16 | Cr(VI)-free | S | 48 | 73079290 | 36 | Steel | CN | ||
113.72 € | 1 | 5 Days | Complete, including nut and ring | 160 | 41 | 36 | 72 | 51 | 0.534 | 22 | 34.5 | 27 | 27.5 | 30 | 35 | 19 | Cr(VI)-free | L | 44 | 73079290 | 36 | Steel | CN | ||
174.34 € | 1 | 5 Days | Complete, including nut and ring | 160 | 46 | 42 | 77 | 52 | 0.798 | 28 | 35.5 | 36 | 30.5 | 34 | 38 | 24 | Cr(VI)-free | L | 47 | 73079290 | 41 | Steel | CN | ||
205.75 € | 1 | 5 Days | EO-2 complete fitting including nut and ring | 160 | 46 | 42 | 77 | 52 | 0.795 | 28 | 35.5 | 36 | 30.5 | 34 | 38 | 24 | Cr(VI)-free | L | 47 | 73079290 | 41 | Steel | CN |
Loading...
Basic information
| Customs tariff weight unit | kg | Order code | WSV | Customs tariff weight per | 1 |
|---|
Configure
Basic Attributes
-
Delivery
-
PN (bar)
-
S2(mm)
-
D4
-
L5
-
L7
-
Customs tariff weight(kg)
-
External pipe diameter D1
-
L4
-
S1
-
L2
-
L3
-
L1
-
D3
-
Surface
-
Model series
-
L6
-
Customs tariff item number
-
S3
-
Engineering material
-
Customs tariff country of origin
Filter by standard shipping days
-
- All
- 5 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
