Linear guideway carriages / recirculating roller system / precision class selectable / RWU45-E
[Specifications]
・Rail Width(mm): 120
・Mounting Height H(mm): 60
・Length L(mm): 145.9
・Rail Width(mm): 120
・Mounting Height H(mm): 60
・Length L(mm): 145.9
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Preload class | Accuracy class | Customs tariff weight | |
|---|---|---|---|---|---|---|---|
- | 1 | 4 Days | G0 | V1 | 3.05 | ||
- | 1 | 4 Days | G1 | V1 | 3.05 | ||
- | 1 | 4 Days | G2 | V1 | 3.05 | ||
- | 1 | 4 Days | G3 | V1 | 3.05 | ||
- | 1 | 4 Days | G0 | V2 | 3.05 | ||
- | 1 | 4 Days | G1 | V2 | 3.05 | ||
- | 1 | 4 Days | G2 | V2 | 3.05 | ||
- | 1 | 4 Days | G3 | V2 | 3.05 | ||
308.62 € | 1 | 12 Days | G2 | V3 | 3.07 | ||
- | 1 | 4 Days | G3 | V3 | 3.07 | ||
- | 1 | 4 Days | G0 | V4 | 3.05 | ||
- | 1 | 4 Days | G1 | V4 | 3.05 | ||
- | 1 | 4 Days | G2 | V4 | 3.05 | ||
- | 1 | 4 Days | G3 | V4 | 3.05 | ||
- | 1 | 4 Days | G0 | V5 | 3.05 | ||
- | 1 | 4 Days | G1 | V5 | 3.05 | ||
- | 1 | 4 Days | G2 | V5 | 3.05 | ||
- | 1 | 4 Days | G3 | V5 | 3.05 |
Loading...
Basic information
| Rail Width(mm) | 120 | Mounting Height H(mm) | 60 | Basic Load Rating: Dynamic Load(N) | 92000 |
|---|---|---|---|---|---|
| Basic Load Rating: Static Load(N) | 215000 | Length L(mm) | 145.9 | RoHS Certificate | Available |
| REACH Certificate | Available | Customs tariff weight unit | kg |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
