Running Disc
・Internal diameter(mm): 10~90
・Outer diameter(mm): 24~120
・eClass code: 23-05-09-03
Universal washers for cylindrical and needle roller thrust bearings are supplied as separate components. They are made of hardened carbon chromium bearing steel and their raceway surface is ground, while all other surfaces are turned. The washers are suitable for applications where accurate centring of the washers is not necessary or where low speeds are involved. They can be used as shaft or housing washers for AXK series bearings, and as shaft washers for AXW series bearings.
[Features]
・Enable full interchangeability of washers
・Suitable where accurate centring of washers is not necessary
・Suitable for low-speed applications
・Available for cylindrical roller thrust bearings in the K 811 series
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| LS 1024 |
| LS 1226 |
| LS 1528 |
| LS 1730 |
| LS 2035 |
| LS 2542 |
| LS 3047 |
| LS 3552 |
| LS 4060 |
| LS 4565 |
| LS 5070 |
| LS 5578 |
| LS 7095 |
| LS 75100 |
| LS 85110 |
| LS 90120 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Internal diameter (mm) | Outer diameter (mm) | Width (mm) | Weight (g) | GTIN/EAN | |
|---|---|---|---|---|---|---|---|---|---|
4.02 € | 1 | 17 Days | 10 | 24 | 2.75 | 7 | 7316570219265 | ||
4.22 € | 1 | 17 Days | 12 | 26 | 2.75 | 8 | 7316570504453 | ||
4.22 € | 1 | 17 Days | 15 | 28 | 2.75 | 9 | 7316570440898 | ||
4.48 € | 1 | 17 Days | 17 | 30 | 2.75 | 8 | - | ||
4.73 € | 1 | 17 Days | 20 | 35 | 2.75 | 14 | 7316570078817 | ||
5.88 € | 10 | 17 Days | 25 | 42 | 3 | 19 | 7316571068718 | ||
6.95 € | 1 | 17 Days | 30 | 47 | 3 | 22 | 7316570331196 | ||
7.93 € | 1 | 17 Days | 35 | 52 | 3.5 | 29.0 | 7316571171210 | ||
8.00 € | 1 | 17 Days | 40 | 60 | 3.5 | 40 | 7316570294569 | ||
9.02 € | 1 | 17 Days | 45 | 65 | 4 | 50.0 | 7316570102086 | ||
10.45 € | 1 | 17 Days | 50 | 70 | 4 | 55.0 | 7316570620153 | ||
12.57 € | 1 | 17 Days | 55 | 78 | 5 | 88 | 7316570629224 | ||
18.10 € | 1 | 17 Days | 70 | 95 | 5.25 | 123.0 | 7316570045055 | ||
37.18 € | 1 | 17 Days | 75 | 100 | 5.74 | 142.0 | 7316570118957 | ||
28.03 € | 1 | 17 Days | 85 | 110 | 5.75 | 159.0 | 7316571121147 | ||
35.88 € | 1 | 17 Days | 90 | 120 | 6.5 | 234.0 | 7316570597332 |
Loading...
Basic information
| Material | Steel, hardened | series | LS | Customs tariff number | 84829900 |
|---|
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
