Double toothed timing belt / Twin Power CTB / B 9,53 / CR (Neoprene) / glass fibre / GATES
· High loading capacity
· Twin Power™ can transmit up to 100% of its maximum rated load from either side of the belt; alternatively, it can transmit a load on both sides - provided the sum of the loads does not exceed the maximum capacity
· Non-slip positive drive
· Running at low noise
· Free of lubrication and maintenance
· Temperature range: -30°C to +100°C
· Twin Power™ can transmit up to 100% of its maximum rated load from either side of the belt; alternatively, it can transmit a load on both sides - provided the sum of the loads does not exceed the maximum capacity
· Non-slip positive drive
· Running at low noise
· Free of lubrication and maintenance
· Temperature range: -30°C to +100°C
(i)Remark
- Product images may be representative images only. Please refer to the manufacturer's catalog for shape details.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
9246-12022
- Product data
- CAD data not available
Basic information
| Belt material | Rubber Belt | Core Wire Material | Glass Cord | Belt Width (mm)(mm) | 9.53 |
|---|---|---|---|---|---|
| Temperature range (min.)(°C) | -30 | Temperature range (max.) | 100 | Pitch(mm) | 5.08 |
| GTIN/EAN | 5412571203431 | Weight(g) | 13.0 | Customs tariff number | 40103500 |
This page is Double toothed timing belt / Twin Power CTB / B 9,53 / CR (Neoprene) / glass fibre / GATES , part number 9246-12022.
You can find the detail information about specifications and dimensions on part number 9246-12022.
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
