Plug-In Y
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| RPY PT0404 |
| RPY PT0505 |
| RPY PT0606 |
| RPY PT0808 |
| RPY PT1010 |
| RPY PT1212 |
| RPY PT1414 |
| RPY PT1616 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Width (mm) | Length (mm) | Fitting ID (mm) | For Tube OD (x2) (mm) | Height (mm) | |
|---|---|---|---|---|---|---|---|---|---|
2.00 € | 10 | 7 Days | 20 | 49 | 4 | 4 | 11 | ||
2.28 € | 10 | 7 Days | 26 | 54 | 5 | 5 | 13 | ||
2.28 € | 10 | 7 Days | 26 | 55 | 6 | 6 | 13 | ||
2.77 € | 10 | 7 Days | 29 | 56 | 8 | 8 | 14 | ||
3.73 € | 10 | 7 Days | 37 | 70 | 10 | 10 | 18 | ||
3.98 € | 5 | 7 Days | 41 | 73 | 12 | 12 | 20 | ||
7.48 € | 5 | 7 Days | 47 | 76 | 14 | 14 | 23 | ||
7.48 € | 5 | 7 Days | 50 | 79 | 16 | 16 | 24 |
Loading...
Basic information
| Max. Operating Pressure(bar) | 10 |
|---|
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
