Horizontal Toggle Clamp Plus with Green Handle, 68300G

Horizontal Toggle Clamp Plus with Green Handle, 68300G

Part number:

Still undefined. 4 possible part numbers found.
Quantity:

Part number list

Number of items
  • 1
    • Part number
    557498
    557499
    557500
    557936

    F1

    (kN)

    F2

    (kN)

    Size

    Weight

    (g)

    		Minimum order quantity
    1,1
    1,7
    1
    114
    1 pieces
    2,5
    4,0
    3
    560
    1 pieces
    3,5
    8,0
    4
    1250
    1 pieces
    1,6
    3,0
    2
    450
    1 pieces
    Unit price (excluding VAT)(Unit price including VAT)
    Standard shipping days
    46.23 €
    ( 55.01 € )
    6 working days
    60.82 €
    ( 72.38 € )
    6 working days
    81.98 €
    ( 97.56 € )
    6 working days
    54.48 €
    ( 64.83 € )
    6 working days
  • 1

    • More Information

    Basic information

    Horizontal toggle clamp plus with green handle
    With increased clamping force, open clamping arm and horizontal base.Galvanised and passivated. Stainless steel rivets. The bearings are pre-lubricated. Ergonomic, oil-resistant handle with large grip surface and soft components. Safety clamping piece with lock washer for the clamping screw at the end of the clamping arm .
    Complete with tempered, galvanised clamping screw no. 68301.
