Stainless Steel Heavy Duty Fixed Castor, BKX-POH Series
Bracket: BKX series
- high-quality chromium-nickel steel (1.4301/AISI 304), stainless steel, vibration-ground finishing
- all parts including axle material are corrosion-resistant
Wheel: POH series
- highly heat-resistant nylon, impact resistant, hardness 85 Shore D, colour natural
- high chemical resistance to many aggressive substances
- operating temperature: -25 °C to +170 °C
- oven temperature temporarily up to +200 °C, wheel temperature must not exceed +170 °C
- Load capacity may be reduced in temperatures over +70 °C
- suitable for autoclaves
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| BKX-POH 102G-1 |
| BKX-POH 102HXK-1 |
| BKX-POH 125G-1 |
| BKX-POH 125HXK-1 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Caster Type | Mounting Height H (mm) | Load Range (daN) | Wheel Characteristics | Wheel Dia. D (mm) | Wheel Width B (mm) | Bearing type | Total height (mm) | Weight (g) | Wheel diameter (mm) | Wheel width (mm) | Load capacity at 4 km/h (kg) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
91.90 € | 1 | 23 Days | Plate Type Swivel / Screw-In Type / Resin / Through Hole Type / Rotation Type | 155 | 220.01 to 320.00 | Heat Resistance | 125 | 40 | plain bore | 130 | 626 | 100 | 38 | 300 | ||
137.32 € | 1 | 23 Days | Plate Type Swivel / Screw-In Type / Through Hole Type / Rotation Type | 130 | 220.01 to 320.00 | - | 100 | 35 | Ball bearing | 130 | 734 | 100 | 38 | 300 | ||
95.95 € | 1 | 23 Days | Plate Type Swivel / Screw-In Type / Through Hole Type / Rotation Type | 130 | 320.01 to 485.00 | - | 100 | 35 | plain bore | 155 | 776 | 125 | 40 | 350 | ||
149.70 € | 1 | 23 Days | Plate Type Swivel / Screw-In Type / Through Hole Type / Rotation Type | 130 | 320.01 to 485.00 | - | 100 | 35 | Ball bearing | 155 | 950 | 125 | 40 | 350 |
Loading...
Basic information
| Wheel Material | Engineering Plastics | Plate Length L(mm) | 100 | Plate Width W(mm) | 85 |
|---|---|---|---|---|---|
| Product type | fixed castor | Suitable for autoclaves | yes | Mounting type | top plate |
| Tread and tyre hardness | 85 Shore D | Tread color | natural | Wheel body color | natural |
| Tread hydrolysis-resistant | no | Non-staining | yes | Rustproof | yes |
| Non-marking | yes | Minimum temperature resistance(°C) | -25 |
Configure
Basic Attributes
-
Caster Type
- Plate Type Swivel
- Screw-In Type
- Resin
- Through Hole Type
- Rotation Type
-
Mounting Height H(mm)
-
Load Range(daN)
- 220.01 to 320.00
- 320.01 to 485.00
-
Wheel Characteristics
- Heat Resistance
-
Wheel Dia. D(mm)
-
Wheel Width B(mm)
-
Bearing type
- Ball bearing
- plain bore
-
Total height(mm)
-
Weight(g)
-
Wheel diameter(mm)
-
Wheel width(mm)
-
Load capacity at 4 km/h(kg)
-
Type
- BKX-POH
Filter by standard shipping days
-
- All
- 23 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
