Pressed Steel Swivel Castor, L-GTH Series
Pressed Steel Swivel Castor, Medium Duty Design, with Top Plate Fitting, with Dead Man’S Brake, Heavy Duty Wheel, with Blickle Extrathane® Polyurethane Tread, with Cast Iron Wheel Centre
Bracket: L series
Bracket: L series
- pressed steel, zinc-plated, blue-passivated, Cr6-free
- double ball bearing in the swivel head
- strong central kingpin (from wheel Ø 150 mm)
- swivel head seal
- minimum swivel head play and smooth rolling characteristic and increased service life due to the special dynamic Blickle riveting process
Wheel: GTH series
- tread: high-quality polyurethane elastomer Blickle Extrathane®, hardness 92 Shore A, colour light brown, non-marking, non-staining
- wheel centre: rugged grey cast iron, lacquered, colour silver
- high chemical resistance to many aggressive substances
- operating temperature: -20 °C to +70 °C, temporarily up to +90 °C, reduced load capacity over +40 °C
- operating angle: max. 38°
- torque required to release the brake: < 10 Nm
- braking force: > 400 N
- Braking can place swivel castors under a significant amount of additional stress, depending on the mass which needs to be braked. We recommend using an additional safety factor of 2.0–3.0 when designing the vehicle / chassis.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| L-GTH 200K-TM13 |
| L-GTH 200K-TTM13 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Weight (g) | |
|---|---|---|---|---|---|
610.25 € | 1 | 23 Days | 6910 | ||
669.24 € | 1 | 23 Days | 6934 |
Loading...
Basic information
| Caster Type | Plate Type Swivel / Screw-In Type / Through Hole Type / Rotation Type | Mounting Height H(mm) | 165 | Load Range(daN) | 320.01 to 485.00 |
|---|---|---|---|---|---|
| Wheel Material | Others | Plate Length L(mm) | 140 | Plate Width W(mm) | 110 |
| Wheel Dia. D(mm) | 125 | Wheel Width B(mm) | 40 | Bearing type | Ball bearing |
| Material (details) | Tread material: Polyurethane, Wheel body material: rugged grey cast iron | Material | Polyurethane | Product type | swivel castor |
| Total height(mm) | 235 | Wheel diameter(mm) | 200 | Wheel width(mm) | 50 |
| Suitable for autoclaves | no | Mounting type | top plate | Tread and tyre hardness | 92 Shore A |
| Tread color | light brown | Wheel body color | silver | Tread hydrolysis-resistant | no |
| Non-staining | yes | Rustproof | no | Non-marking | yes |
| Maximum temperature resistance(°C) | 70 | Minimum temperature resistance(°C) | -20 | Load capacity at 4 km/h(kg) | 400 |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
