MAEDLER

Elastic Couplings MAEPEX®

Elastic Couplings MAEPEX®

Part number:

Still undefined. 13 possible part numbers found.
Quantity:

Part number list

Number of items
  • 1
    • Part number
    60560001
    60560002
    60560003
    60560004
    60560005
    60560006
    60560007
    60560008
    60560009
    60560010
    60560011
    60560012
    60560013

    Allowable Torque Range

    (N•m)

    Allowable Torque

    (Nm)

    Size

    Nominal torque

    (Nm)

    Bore (pilot hole)

    (mm)

    Max. bore (d1) d1 max.

    (mm)

    Max. bore (d2) d2 max.

    (mm)

    Max. misalignment axial

    (mm)

    Outer diameter DH

    (mm)

    Hub diameter (D1) D1

    (mm)

    Hub diameter (D2) D2

    (mm)

    Distance between the hubs E

    (mm)

    Total length L

    (mm)

    Hub length l

    (mm)

    Flange width (l3) l3

    (mm)

    Flange width (l4) l4

    (mm)

    Wear limit of backlash, measured at the circumference Smax.

    (mm)

    Max. speed

    (min-1)

    Weight

    (kg)

    		Minimum order quantity
    50.01 to 100.00
    57
    58
    19
    Without bore
    19
    24
    2
    58
    -
    40
    2 - 4
    42
    20
    20
    8
    5.5
    5000
    0.53
    1 pieces
    100 to Less Than 500
    102
    68
    34
    Without bore
    24
    28
    2
    68
    -
    50
    2 - 4
    42
    20
    20
    8
    5.5
    5000
    0.744
    1 pieces
    100 to Less Than 500
    180
    80
    60
    Without bore
    30
    38
    2
    80
    -
    68
    2 - 4
    62
    30
    30
    10
    5
    5000
    1.79
    1 pieces
    100 to Less Than 500
    300
    95
    100
    Without bore
    42
    42
    2
    95
    76
    76
    2 - 4
    72
    35
    30
    12
    6
    5000
    2.76
    1 pieces
    100 to Less Than 500
    480
    110
    160
    Without bore
    48
    48
    2
    110
    86
    86
    2 - 4
    82
    40
    34
    14
    7
    5000
    4.13
    1 pieces
    500 to Less Than 1,000
    720
    125
    240
    Without bore
    55
    55
    2
    125
    100
    100
    2 - 4
    102
    50
    36
    18
    8
    5000
    6.66
    1 pieces
    1000 to Less Than 5000
    1080
    140
    360
    Without bore
    60
    60
    2
    140
    100
    100
    2 - 4
    112
    55
    34
    20
    8
    4900
    8.25
    1 pieces
    1000 to Less Than 5000
    1680
    160
    560
    Without bore
    65
    65
    2
    160
    108
    108
    2 - 6
    122
    60
    40
    20
    8
    4250
    11.04
    1 pieces
    1000 to Less Than 5000
    2640
    180
    880
    Without bore
    75
    75
    2
    180
    125
    125
    2 - 6
    142
    70
    42
    20
    8
    3800
    16.45
    1 pieces
    1000 to Less Than 5000
    4020
    200
    1340
    Without bore
    85
    85
    2
    200
    140
    140
    2 - 6
    162
    80
    47
    24
    8.5
    3400
    23.72
    1 pieces
    5,000 to Less Than 10,000
    6000
    225
    2000
    Without bore
    90
    90
    2
    225
    150
    150
    2 - 6
    182
    90
    52
    18
    9
    3000
    30.63
    1 pieces
    5,000 to Less Than 10,000
    8400
    250
    2800
    44
    100
    100
    3
    250
    165
    165
    3 - 8
    203
    100
    60
    18
    10
    2750
    39.46
    1 pieces
    10,000 to Less than 20,000
    10000
    280
    3900
    52 | 47
    110
    110
    3
    280
    180
    172
    3 - 8
    223
    110
    65
    20
    11.5
    2450
    52.58
    1 pieces
    Unit price (excluding VAT)(Unit price including VAT)
    Standard shipping days
    56.30 €
    ( 67.00 € )
    4 working days
    66.42 €
    ( 79.04 € )
    4 working days
    78.60 €
    ( 93.53 € )
    4 working days
    91.18 €
    ( 108.50 € )
    4 working days
    127.78 €
    ( 152.06 € )
    4 working days
    170.21 €
    ( 202.55 € )
    4 working days
    224.57 €
    ( 267.24 € )
    4 working days
    260.46 €
    ( 309.95 € )
    4 working days
    327.42 €
    ( 389.63 € )
    4 working days
    403.16 €
    ( 479.76 € )
    4 working days
    479.51 €
    ( 570.62 € )
    4 working days
    525.20 €
    ( 624.99 € )
    4 working days
    652.02 €
    ( 775.90 € )
    4 working days
  • 1

    • More Information

    Basic information

    Material: Coupling hubs: Grey Cast Iron GG25 (GJL-250).
    Elastomers: NBR, hardness 80ºA Shore, black.
    Torsionally flexible cam coupling, fail-safe, with damping effect.
    The MÄDLER® version is improved:
    Machined claws result in longer lifetime.
    Couplings are non-bored or pre-bored, depending on the size.
    Customized bores and feather-key grooves available at extra charge.
    Temperature range: -30ºC to +80ºC.
