Cam-action indexing plunger, steel with hexagon, Form B (03099-12)

Part number:

Still undefined. 24 possible part numbers found.
Quantity:

Part number list

Number of items

Thread

(mm)

B

(mm)

B1

(mm)

D=locking pin diameter

(mm)

D2

(mm)

Fx30°

(mm)

H

(mm)

L

(mm)

L1=Handle length

(mm)

L3

(mm)

SW1

(mm)

SW2

(mm)

Spring force final pressure F2 approx.

(N)

Spring force initial pressure F1 approx.

(N)

Weight (ERP)

(kg)

Minimum order quantity
10
9
3
4
10
1
6
38.5
25
15
10
17
14
8
0.0294
1 pieces
10x1
9
3
4
10
1
6
38.5
25
15
10
17
14
8
0.0294
1 pieces
10
9
3
5
10
1.3
6
38.5
25
15
10
17
14
8
0.0297
1 pieces
12
10.8
3.6
5
12
1.3
8
47.4
30
19
12
19
15
8
0.0470
1 pieces
10x1
9
3
5
10
1.3
6
38.5
25
15
10
17
14
8
0.0297
1 pieces
12x1.5
10.8
3.6
5
12
1.3
8
47.4
30
19
12
19
15
8
0.0470
1 pieces
10
9
3
6
10
1.8
6
38.5
25
15
10
17
14
8
0.0300
1 pieces
12
10.8
3.6
6
12
1.8
8
47.4
30
19
12
19
15
8
0.0474
1 pieces
16
14.4
4.8
6
16
1.8
10
61.2
40
26
16
24
35
15
0.1090
1 pieces
10x1
9
3
6
10
1.8
6
38.5
25
15
10
17
14
8
0.0300
1 pieces
12x1.5
10.8
3.6
6
12
1.8
8
47.4
30
19
12
19
15
8
0.0474
1 pieces
16x1.5
14.4
4.8
6
16
1.8
10
61.2
40
26
16
24
35
15
0.0930
1 pieces
12
10.8
3.6
8
12
2.3
8
47.4
30
19
12
19
15
8
0.0485
1 pieces
16
14.4
4.8
8
16
2.3
10
61.2
40
26
16
24
35
15
0.1110
1 pieces
20
18
6
8
20
2.3
12
71
50
30
20
30
60
20
0.1982
1 pieces
12x1.5
10.8
3.6
8
12
2.3
8
47.4
30
19
12
19
15
8
0.0485
1 pieces
16x1.5
14.4
4.8
8
16
2.3
10
61.2
40
26
16
24
35
15
0.1110
1 pieces
20x1.5
18
6
8
20
2.3
12
71
50
30
20
30
60
20
0.1982
1 pieces
16
14.4
4.8
10
16
2.8
10
61.2
40
26
16
24
35
15
0.1123
1 pieces
20
18
6
10
20
2.8
12
71
50
30
20
30
60
20
0.2015
1 pieces
16x1.5
14.4
4.8
10
16
2.8
10
61.2
40
26
16
24
35
15
0.1123
1 pieces
20x1.5
18
6
10
20
2.8
12
71
50
30
20
30
60
20
0.2015
1 pieces
20
18
6
12
20
3
12
71
50
30
20
30
60
20
0.2033
1 pieces
20x1.5
18
6
12
20
3
12
71
50
30
20
30
60
20
0.2033
1 pieces
Unit price (excluding VAT)(Unit price including VAT)
Standard shipping days
16.20 €
( 19.28 € )
4 working days
16.20 €
( 19.28 € )
4 working days
16.20 €
( 19.28 € )
4 working days
16.39 €
( 19.50 € )
4 working days
16.20 €
( 19.28 € )
4 working days
16.39 €
( 19.50 € )
4 working days
16.20 €
( 19.28 € )
4 working days
16.39 €
( 19.50 € )
4 working days
19.71 €
( 23.45 € )
4 working days
16.20 €
( 19.28 € )
4 working days
16.39 €
( 19.50 € )
4 working days
19.71 €
( 23.45 € )
4 working days
16.39 €
( 19.50 € )
4 working days
19.71 €
( 23.45 € )
4 working days
22.70 €
( 27.01 € )
4 working days
16.39 €
( 19.50 € )
4 working days
19.71 €
( 23.45 € )
4 working days
22.70 €
( 27.01 € )
4 working days
19.71 €
( 23.45 € )
4 working days
22.70 €
( 27.01 € )
4 working days
19.71 €
( 23.45 € )
4 working days
22.70 €
( 27.01 € )
4 working days
22.70 €
( 27.01 € )
4 working days
22.70 €
( 27.01 € )
4 working days

More Information

Basic information

· Turning the grip through 180° retracts the indexing pin.

· Optionally available with coloured plastic grip caps

· Sleeves with a hexagon serve as assembly aids
