Clamping lever with push button, internal thread, plastic, inch (06601)
· Makes it easier to clamp devices or machine parts
· Application fields: machine construction, plant construction, rehabilitation and medical technology, furniture industry
· Push button eases the release and makes handling the lever safer.
· Various colour combinations
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | A | H | B | D | Main colour | Component colour | Size | X=thread | D1 (mm) | No. of teeth | A1=Handle length | D2 | H1 | H2 | H3=handle height | H4 | T=thread depth | Weight in kg (ERP) (kg) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
9.33 € | 1 | 4 Days | 40 | 25.5 | 7.5 | 10 | black grey RAL 7021 | traffic red RAL 3020 | 1 | 10-24 | 13 | 16 | 47 | 14.5 | 4 | 15 | 30 | 33.5 | 9 | 0.0130 | ||
9.33 € | 1 | 4 Days | 40 | 25.5 | 7.5 | 10 | black grey RAL 7021 | traffic red RAL 3020 | 1 | 10-32 | 13 | 16 | 47 | 14.5 | 4 | 15 | 30 | 33.5 | 9 | 0.0130 | ||
9.33 € | 1 | 4 Days | 40 | 25.5 | 7.5 | 10 | black grey RAL 7021 | traffic red RAL 3020 | 1 | 1/4-20 | 13 | 16 | 47 | 14.5 | 4 | 15 | 30 | 33.5 | 9 | 0.0130 | ||
11.01 € | 1 | 4 Days | 65 | 29.5 | 9.5 | 13.5 | black grey RAL 7021 | traffic red RAL 3020 | 2 | 1/4-20 | 18 | 20 | 75 | 19.5 | 6.5 | 17.5 | 41.5 | 45.5 | 12 | 0.0290 | ||
11.01 € | 1 | 4 Days | 65 | 29.5 | 9.5 | 13.5 | black grey RAL 7021 | traffic red RAL 3020 | 2 | 5/16-18 | 18 | 20 | 75 | 19.5 | 6.5 | 17.5 | 41.5 | 45.5 | 12 | 0.0290 | ||
13.55 € | 1 | 4 Days | 80 | 38.5 | 11 | 16 | black grey RAL 7021 | traffic red RAL 3020 | 3 | 5/16-18 | 21.5 | 22 | 91.5 | 23 | 10 | 24 | 53.5 | 58 | 14 | 0.0500 | ||
13.55 € | 1 | 4 Days | 80 | 38.5 | 11 | 16 | black grey RAL 7021 | traffic red RAL 3020 | 3 | 3/8-16 | 21.5 | 22 | 91.5 | 23 | 10 | 24 | 53.5 | 58 | 14 | 0.0500 | ||
19.49 € | 1 | 4 Days | 95 | 44.6 | 13 | 19 | black grey RAL 7021 | traffic red RAL 3020 | 4 | 3/8-16 | 25.5 | 24 | 109 | 27.5 | 10 | 26 | 61 | 66 | 17 | 0.0780 | ||
19.49 € | 1 | 4 Days | 95 | 44.6 | 13 | 19 | black grey RAL 7021 | traffic red RAL 3020 | 4 | 1/2-13 | 25.5 | 24 | 109 | 27.5 | 10 | 26 | 61 | 66 | 17 | 0.0780 | ||
23.52 € | 1 | 4 Days | 110 | 50.6 | 15.5 | 23 | black grey RAL 7021 | traffic red RAL 3020 | 5 | 1/2-13 | 30 | 26 | 126 | 32.5 | 12 | 33 | 72 | 77 | 23 | 0.1300 | ||
23.52 € | 1 | 4 Days | 110 | 50.6 | 15.5 | 23 | black grey RAL 7021 | traffic red RAL 3020 | 5 | 5/8-11 | 30 | 26 | 126 | 32.5 | 12 | 33 | 72 | 77 | 23 | 0.1300 | ||
9.33 € | 1 | 4 Days | 40 | 25.5 | 7.5 | 10 | orange RAL 2004 | black grey RAL 7021 | 1 | 10-24 | 13 | 16 | 47 | 14.5 | 4 | 15 | 30 | 33.5 | 9 | 0.0130 | ||
9.33 € | 1 | 4 Days | 40 | 25.5 | 7.5 | 10 | orange RAL 2004 | black grey RAL 7021 | 1 | 10-32 | 13 | 16 | 47 | 14.5 | 4 | 15 | 30 | 33.5 | 9 | 0.0130 | ||
9.33 € | 1 | 4 Days | 40 | 25.5 | 7.5 | 10 | orange RAL 2004 | black grey RAL 7021 | 1 | 1/4-20 | 13 | 16 | 47 | 14.5 | 4 | 15 | 30 | 33.5 | 9 | 0.0130 | ||
11.01 € | 1 | 4 Days | 65 | 29.5 | 9.5 | 13.5 | orange RAL 2004 | black grey RAL 7021 | 2 | 1/4-20 | 18 | 20 | 75 | 19.5 | 6.5 | 17.5 | 41.5 | 45.5 | 12 | 0.0290 | ||
11.01 € | 1 | 4 Days | 65 | 29.5 | 9.5 | 13.5 | orange RAL 2004 | black grey RAL 7021 | 2 | 5/16-18 | 18 | 20 | 75 | 19.5 | 6.5 | 17.5 | 41.5 | 45.5 | 12 | 0.0290 | ||
13.55 € | 1 | 4 Days | 80 | 38.5 | 11 | 16 | orange RAL 2004 | black grey RAL 7021 | 3 | 5/16-18 | 21.5 | 22 | 91.5 | 23 | 10 | 24 | 53.5 | 58 | 14 | 0.0500 | ||
13.55 € | 1 | 4 Days | 80 | 38.5 | 11 | 16 | orange RAL 2004 | black grey RAL 7021 | 3 | 3/8-16 | 21.5 | 22 | 91.5 | 23 | 10 | 24 | 53.5 | 58 | 14 | 0.0500 | ||
19.49 € | 1 | 4 Days | 95 | 44.6 | 13 | 19 | orange RAL 2004 | black grey RAL 7021 | 4 | 3/8-16 | 25.5 | 24 | 109 | 27.5 | 10 | 26 | 61 | 66 | 17 | 0.0780 | ||
19.49 € | 1 | 4 Days | 95 | 44.6 | 13 | 19 | orange RAL 2004 | black grey RAL 7021 | 4 | 1/2-13 | 25.5 | 24 | 109 | 27.5 | 10 | 26 | 61 | 66 | 17 | 0.0780 | ||
23.52 € | 1 | 4 Days | 110 | 50.6 | 15.5 | 23 | orange RAL 2004 | black grey RAL 7021 | 5 | 1/2-13 | 30 | 26 | 126 | 32.5 | 12 | 33 | 72 | 77 | 23 | 0.1300 | ||
23.52 € | 1 | 4 Days | 110 | 50.6 | 15.5 | 23 | orange RAL 2004 | black grey RAL 7021 | 5 | 5/8-11 | 30 | 26 | 126 | 32.5 | 12 | 33 | 72 | 77 | 23 | 0.1300 | ||
9.33 € | 1 | 4 Days | 40 | 25.5 | 7.5 | 10 | traffic red RAL 3020 | black grey RAL 7021 | 1 | 10-24 | 13 | 16 | 47 | 14.5 | 4 | 15 | 30 | 33.5 | 9 | 0.0130 | ||
9.33 € | 1 | 4 Days | 40 | 25.5 | 7.5 | 10 | traffic red RAL 3020 | black grey RAL 7021 | 1 | 10-32 | 13 | 16 | 47 | 14.5 | 4 | 15 | 30 | 33.5 | 9 | 0.0130 | ||
9.33 € | 1 | 4 Days | 40 | 25.5 | 7.5 | 10 | traffic red RAL 3020 | black grey RAL 7021 | 1 | 1/4-20 | 13 | 16 | 47 | 14.5 | 4 | 15 | 30 | 33.5 | 9 | 0.0130 | ||
11.01 € | 1 | 4 Days | 65 | 29.5 | 9.5 | 13.5 | traffic red RAL 3020 | black grey RAL 7021 | 2 | 1/4-20 | 18 | 20 | 75 | 19.5 | 6.5 | 17.5 | 41.5 | 45.5 | 12 | 0.0290 | ||
11.01 € | 1 | 4 Days | 65 | 29.5 | 9.5 | 13.5 | traffic red RAL 3020 | black grey RAL 7021 | 2 | 5/16-18 | 18 | 20 | 75 | 19.5 | 6.5 | 17.5 | 41.5 | 45.5 | 12 | 0.0290 | ||
13.55 € | 1 | 4 Days | 80 | 38.5 | 11 | 16 | traffic red RAL 3020 | black grey RAL 7021 | 3 | 5/16-18 | 21.5 | 22 | 91.5 | 23 | 10 | 24 | 53.5 | 58 | 14 | 0.0500 | ||
13.55 € | 1 | 4 Days | 80 | 38.5 | 11 | 16 | traffic red RAL 3020 | black grey RAL 7021 | 3 | 3/8-16 | 21.5 | 22 | 91.5 | 23 | 10 | 24 | 53.5 | 58 | 14 | 0.0500 | ||
19.49 € | 1 | 4 Days | 95 | 44.6 | 13 | 19 | traffic red RAL 3020 | black grey RAL 7021 | 4 | 3/8-16 | 25.5 | 24 | 109 | 27.5 | 10 | 26 | 61 | 66 | 17 | 0.0780 | ||
19.49 € | 1 | 4 Days | 95 | 44.6 | 13 | 19 | traffic red RAL 3020 | black grey RAL 7021 | 4 | 1/2-13 | 25.5 | 24 | 109 | 27.5 | 10 | 26 | 61 | 66 | 17 | 0.0780 | ||
23.52 € | 1 | 4 Days | 110 | 50.6 | 15.5 | 23 | traffic red RAL 3020 | black grey RAL 7021 | 5 | 1/2-13 | 30 | 26 | 126 | 32.5 | 12 | 33 | 72 | 77 | 23 | 0.1300 | ||
23.52 € | 1 | 4 Days | 110 | 50.6 | 15.5 | 23 | traffic red RAL 3020 | black grey RAL 7021 | 5 | 5/8-11 | 30 | 26 | 126 | 32.5 | 12 | 33 | 72 | 77 | 23 | 0.1300 |
Loading...
Basic information
| Main material | Plastic | Component material | Stainless steel | Item | Clamping Lever |
|---|---|---|---|---|---|
| Thread type | internal thread | Version 1 | with push button | RoHS | yes |
