Clamping arm for swing clamp, form A (04368)
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| 04368-30-25502 |
| 04368-30-40752 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | L | H | D | L2 | D1 (mm) | D2 | For piston Ø | G | H4 | H5 | L1 | R | R1 | Weight in kg (ERP) (kg) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
49.51 € | 1 | 4 Days | 75 | 16 | 20 | 16 | 16 | 9 | 25 | M10 | 10 | 64 | 50 | 16 | 9 | 0.2000 | ||
65.92 € | 1 | 4 Days | 115 | 23 | 32 | 25 | 25 | 15 | 40 | M16 | 15 | 79 | 75 | 25 | 15 | 0.7000 |
Loading...
Basic information
| Main material | Steel | Surface finish body | black oxidised | Form | A |
|---|---|---|---|---|---|
| Form definition | Thread with thrust screw | Item | Clamping Arm | Version 1 | for swing clamp |
| Version 2 | hydraulic | RoHS | yes | PL Edelstahl | no |
Configure
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
