Spur gears, plastic, module 0.5 injection moulded, straight teeth, engagement angle 20° (22402)

Configure

Number of Teeth(Teeth)
- 12
- 13
- 14
- 15
- 16
- 17
- 18
- 19
- 20
- 21
- 22
- 23
- 24
- 25
- 26
- 27
- 28
- 30
- 32
- 35
- 36
- 38
- 40
- 42
- 45
- 48
- 50
- 52
- 54
- 55
- 56
- 60
- 64
- 65
- 70
- 72
- 75
- 80
- 90
- 96
- 100
- 120
Main material
- Polyacetal
- Polyketone
D
- 7
- 7.5
- 8
- 8.5
- 9
- 9.5
- 10
- 10.5
- 11
- 11.5
- 12
- 12.5
- 13
- 13.5
- 14
- 14.5
- 15
- 16
- 17
- 18.5
- 19
- 20
- 21
- 22
- 23.5
- 25
- 26
- 27
- 28
- 28.5
- 29
- 31
- 33
- 33.5
- 36
- 37
- 38.5
- 41
- 46
- 49
- 51
- 61
D1=Pitch circle diameter(mm)
- 6
- 6.5
- 7
- 7.5
- 8
- 8.5
- 9
- 9.5
- 10
- 10.5
- 11
- 11.5
- 12
- 12.5
- 13
- 13.5
- 14
- 15
- 16
- 17.5
- 18
- 19
- 20
- 21
- 22.5
- 24
- 25
- 26
- 27
- 27.5
- 28
- 30
- 32
- 32.5
- 35
- 36
- 37.5
- 40
- 45
- 48
- 50
- 60
D2=Fastening hole
- 2
- 3
- 4
- 6
D3(mm)
- 4
- 5
- 6
- 7.8
- 7.9
- 8
- 9.9
- 10
- 11.9
- 12
- 12.15
- 15
D4(mm)
- 14.8
- 17
- 18
- 19
- 20
- 21
- 23
- 29
- 30
- 33
- 39
- 42
- 44
- 54
B1(mm)
- 2
- 3
L(mm)
- 7
- 10
Max. Torque(Ncm)
- 1.4
- 1.5
- 1.6
- 1.7
- 1.8
- 1.9
- 2
- 2.1
- 2.2
- 2.3
- 2.4
- 2.5
- 2.7
- 2.8
- 2.9
- 3
- 3.1
- 3.2
- 3.3
- 3.4
- 3.5
- 3.7
- 3.9
- 4.1
- 4.2
- 4.3
- 4.4
- 4.7
- 4.9
- 5.2
- 5.3
- 5.5
- 5.6
- 5.8
- 5.9
- 6.1
- 6.3
- 6.4
- 6.6
- 6.8
- 6.9
- 7
- 7.4
- 7.5
- 7.6
- 7.9
- 8
- 8.2
- 8.4
- 8.6
- 8.8
- 8.9
- 9.2
- 9.4
- 9.8
- 10.6
- 11.1
- 11.3
- 11.7
- 11.8
- 12.3
- 14.1
- 14.8
Est. shipping days
- All
- Within 4 working days

Spur gears, plastic, module 0.5 injection moulded, straight teeth, engagement angle 20° (22402)

Catalog

Part number:

Still undefined. 84 possible part numbers found.

Part number list
More Information
Catalog

Part number list

Number of items

Part number

Number of Teeth

(Teeth)

Main material

D1=Pitch circle diameter

(mm)

D2=Fastening hole

(mm)

Max. Torque

(Ncm)

Weight (ERP)

(kg)

Minimum order quantity

12	Polyacetal	7	6	2	4	-	3	7	1.4	0.0002	1 pieces
13	Polyacetal	7.5	6.5	2	4	-	3	7	1.5	0.0002	1 pieces
14	Polyacetal	8	7	2	5	-	3	7	1.6	0.0002	1 pieces
15	Polyacetal	8.5	7.5	3	6	-	3	10	1.7	0.0004	1 pieces
16	Polyacetal	9	8	3	6	-	3	10	1.8	0.0004	1 pieces
17	Polyacetal	9.5	8.5	3	6	-	3	10	2	0.0004	1 pieces
18	Polyacetal	10	9	4	7.8	-	3	10	2.1	0.0005	1 pieces
19	Polyacetal	10.5	9.5	4	7.8	-	3	10	2.2	0.0006	1 pieces
20	Polyacetal	11	10	4	7.9	-	3	10	2.3	0.0006	1 pieces
21	Polyacetal	11.5	10.5	4	8	-	3	10	2.4	0.0007	1 pieces
22	Polyacetal	12	11	4	10	-	3	10	2.5	0.0009	1 pieces
23	Polyacetal	12.5	11.5	4	9.9	-	3	10	2.7	0.0010	1 pieces
24	Polyacetal	13	12	4	9.9	-	3	10	2.8	0.0010	1 pieces
25	Polyacetal	13.5	12.5	4	9.9	-	3	10	2.9	0.0010	1 pieces
26	Polyacetal	14	13	4	9.9	-	3	10	3	0.0011	1 pieces
27	Polyacetal	14.5	13.5	4	9.9	-	3	10	3.1	0.0011	1 pieces
28	Polyacetal	15	14	4	10	-	3	10	3.3	0.0012	1 pieces
30	Polyacetal	16	15	4	11.9	-	3	10	3.5	0.0016	1 pieces
32	Polyacetal	17	16	4	12	-	3	10	3.7	0.0017	1 pieces
35	Polyacetal	18.5	17.5	4	12	-	3	10	4.1	0.0019	1 pieces
36	Polyacetal	19	18	4	11.9	-	3	10	4.2	0.0019	1 pieces
38	Polyacetal	20	19	4	12	-	3	10	4.4	0.0020	1 pieces
40	Polyacetal	21	20	4	12	14.8	2	10	4.7	0.0021	1 pieces
42	Polyacetal	22	21	4	12.15	17	2	10	4.9	0.0022	1 pieces
45	Polyacetal	23.5	22.5	4	12.15	18	2	10	5.3	0.0024	1 pieces
48	Polyacetal	25	24	6	15	19	2	10	5.6	0.0030	1 pieces
50	Polyacetal	26	25	6	15	20	2	10	5.8	0.0031	1 pieces
52	Polyacetal	27	26	6	15	21	2	10	6.1	0.0032	1 pieces
54	Polyacetal	28	27	6	15	21	2	10	6.3	0.0034	1 pieces
55	Polyacetal	28.5	27.5	6	15	23	2	10	6.4	0.0035	1 pieces
56	Polyacetal	29	28	6	15	23	2	10	6.6	0.0036	1 pieces
60	Polyacetal	31	30	6	15	23	2	10	7	0.0039	1 pieces
64	Polyacetal	33	32	6	15	23	2	10	7.5	0.0043	1 pieces
65	Polyacetal	33.5	32.5	6	15	23	2	10	7.6	0.0045	1 pieces
70	Polyacetal	36	35	6	15	29	2	10	8.2	0.0047	1 pieces
72	Polyacetal	37	36	6	15	30	2	10	8.4	0.0049	1 pieces
75	Polyacetal	38.5	37.5	6	15	33	2	10	8.8	0.0050	1 pieces
80	Polyacetal	41	40	6	15	33	2	10	9.4	0.0055	1 pieces
90	Polyacetal	46	45	6	15	39	2	10	10.6	0.0067	1 pieces
96	Polyacetal	49	48	6	15	42	2	10	11.3	0.0069	1 pieces
100	Polyacetal	51	50	6	15	44	2	10	11.7	0.0075	1 pieces
120	Polyacetal	61	60	6	15	54	2	10	14.1	0.0106	1 pieces
12	Polyketone	7	6	2	4	-	3	7	1.4	0.0001	1 pieces
13	Polyketone	7.5	6.5	2	4	-	3	7	1.6	0.0002	1 pieces
14	Polyketone	8	7	2	5	-	3	7	1.7	0.0002	1 pieces
15	Polyketone	8.5	7.5	3	6	-	3	10	1.8	0.0003	1 pieces
16	Polyketone	9	8	3	6	-	3	10	1.9	0.0003	1 pieces
17	Polyketone	9.5	8.5	3	6	-	3	10	2.1	0.0004	1 pieces
18	Polyketone	10	9	4	7.8	-	3	10	2.2	0.0005	1 pieces
19	Polyketone	10.5	9.5	4	7.8	-	3	10	2.3	0.0005	1 pieces
20	Polyketone	11	10	4	7.9	-	3	10	2.4	0.0005	1 pieces
21	Polyketone	11.5	10.5	4	8	-	3	10	2.5	0.0006	1 pieces
22	Polyketone	12	11	4	10	-	3	10	2.7	0.0008	1 pieces
23	Polyketone	12.5	11.5	4	9.9	-	3	10	2.8	0.0009	1 pieces
24	Polyketone	13	12	4	9.9	-	3	10	2.9	0.0009	1 pieces
25	Polyketone	13.5	12.5	4	9.9	-	3	10	3.1	0.0009	1 pieces
26	Polyketone	14	13	4	9.9	-	3	10	3.2	0.0010	1 pieces
27	Polyketone	14.5	13.5	4	9.9	-	3	10	3.3	0.0010	1 pieces
28	Polyketone	15	14	4	10	-	3	10	3.4	0.0011	1 pieces
30	Polyketone	16	15	4	11.9	-	3	10	3.7	0.0014	1 pieces
