Male Header with Solder Pin / 733 Series, Grade 1 / Right Angle / 2.5mm Pitch
- Volume Discount
● Can be horizontally or vertically mounted on a printed circuit board using a header with right angle solder pins.
● Model that makes incorrect insertion impossible: Only matches with the same number of terminals can be latched.
● An accessory coding key can be attached.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| 733-362 |
| 733-363 |
| 733-364 |
| 733-365 |
| 733-366 |
| 733-368 |
| 733-370 |
| 733-372 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | RoHS | Number Of Cores | |
|---|---|---|---|---|---|---|
0.84 € | 5 | Available | 5 Days | 10 | 2 | |
1.21 € | 5 | Available | 5 Days | 10 | 3 | |
1.62 € | 1 | Available | 5 Days | 10 | 4 | |
1.91 € | 1 | Available | 5 Days | 10 | 5 | |
2.38 € | 1 | Available | 5 Days | 10 | 6 | |
3.03 € | 1 | Available | 5 Days | 10 | 8 | |
3.83 € | 1 | Available | 5 Days | 10 | 10 | |
4.50 € | 1 | Available | 5 Days | 10 | 12 |
Loading...
Basic information
| Connector Shape | Square shape | Connector series initials | M/N/O | M/N/O | MCS-MICRO |
|---|---|---|---|---|---|
| Applicable pin/contact | Male (plug) | Application | For PCB | Allowable Current(A) | 4 |
| Allowable Voltage(V) | 150 | Connection direction | Right Angle | Representative Standard | UL / CUL / CSA |
| Color | Light Gray | Pin pitch(mm) | 2.5 | Terminal length(mm) | 3.7 |
| Insulation materials | Nylon 6.6 | Flame-Retardant Grade | UL94/V0 | Contact materials | Electric copper |
| Contact surface treatment | Tin Plating | Supported accessories | Coating key |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
