EPIC® H-B 24 SDRL-BO
- Volume Discount
The universal metal housing with 2 cable entries and pivots for a double lever is suitable for use in investment construction applications.Housing design H-B. The industry standard.For easy introduction of two cablesMetal lid with sturdy hingeProtection rating UL50E tested
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Basic information
| Degree of protection (IP), mounted | IP65 | Height | 64 | Length | 120 |
|---|---|---|---|---|---|
| Width | 43 | Operation temperature | 125 | Inflammability class of insulation material acc. with UL94 | HB |
| Housing coating | With powder coating | Locking mechanism | Double locking levers | Position cable feed | Two-sided |
| Position of the shackle | Cover | Material housing | Aluminium | Type of housing | Socket case |
| Corrosion resistant | True | EMC-version | False | UV resistant | True |
| With cable screw gland | False | With hinged lid | True | With interlocking device | True |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
