SM TFT monitor
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| 6450010 |
| 6450020 |
| 6450070 |
| 6450170 |
| Part Number | Related to |
Standard Unit Price
| Minimum order quantity | Volume Discount | Height (mm) | Width (mm) | Screen diagonal (inch) | Number of colours of the display | Resolution of display (max. pixels) | With touch screen | |
|---|---|---|---|---|---|---|---|---|---|---|---|
1,918.57 € | 1 | Available | 7 Days | 343 | 430 | 15 | 16.2 | 1024 x 768 | false | ||
2,361.43 € | 1 | Available | 7 Days | 354.8 | 482.6 | 17 | 16.7 | 1280 x 1024 | false | ||
2,677.14 € | 1 | Available | 7 Days | 343 | 430 | 15 | 16.2 | 1024 x 768 | true | ||
3,126.30 € | 1 | Available | 7 Days | 399.3 | 482.6 | 19 | 16.2 | 1280 x 1024 | false |
Loading...
Basic information
| Frame frequency(kHz) | 60 - 75 | Number of grey-scales/blue-scales of display | 3 | Degree of protection (IP) | IP65 |
|---|---|---|---|---|---|
| Type of display | TFT | Voltage type | DC | With HW-interface | PS2/USB/video signal, analogue/digital video signal |
| Mouse-cursor control integrated | true | Display | Colour/On Screen | Front build in possible | true |
| Rack-assembly possible | true |
Configure
Basic Attributes
-
Height(mm)
-
Width(mm)
-
Screen diagonal(inch)
-
Number of colours of the display
- 16.2
- 16.7
-
Resolution of display (max. pixels)
- 1024 x 768
- 1280 x 1024
-
With touch screen
- false
- true
-
Filter by CAD data type
- 2D
- 3D
Filter by standard shipping days
-
- All
- 7 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
