Universal switching element RAFIX 16
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| 1.20123.001 |
| 1.20123.021 |
| 1.20123.031 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Switching capacity (mW) | Switching current (inductive) (A) | Switching current (max.) (A) | Switching current (A) | Switching voltage (Vdc) | Contact material | Switch features | Type (misc.) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
16.93 € | 1 | Available | 3 Days | 6(4) A/250 V | 4 | 6 | 6 (4) | 250 | Silver (Ag) | + bulb holder | incl. lamp holder | |
14.81 € | 1 | Available | 3 Days | 6(4) A/250 V | 4 | 6 | 6 (4) | 250 | Silver (Ag) | - | without lamp holder | |
22.35 € | 1 | Available | 3 Days | 250 mA/42 | - | 0.25 | 250 | 42 | Gold (Au) | - | without lamp holder |
Loading...
Basic information
| Connection | Spade connections 4.8 x 0.8 mm | Connection (components) | Type C CEE 7/16 plug 2.8 mm | Contact type | 1 maker |
|---|---|---|---|---|---|
| Electrical lifespan | 2 x 106 Switching operations | Functions (switches) | momentary | Mounting type | Front panel fixed |
| Switch type (category) | Contact |
Configure
Basic Attributes
-
Switching capacity(mW)
- 6(4) A/250 V
- 250 mA/42
-
Switching current (inductive)(A)
- 4
-
Switching current (max.)(A)
- 0.25
- 6
-
Switching current(A)
- 6 (4)
- 250
-
Switching voltage(Vdc)
- 42
- 250
-
Contact material
- Gold (Au)
- Silver (Ag)
-
Switch features
- + bulb holder
-
Type (misc.)
Filter by standard shipping days
-
- All
- 3 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
