1-Conductor start module 769【250 Pieces Per Package】

Basic Attributes

• Number of pins(Pole)

  • 1

  Clear

• Product size (height)(mm)

  • 37.1
  • 45.2

  Clear

• Product size (width)(mm)

  • 5

  Clear

• Clamp width(mm)

  • 5

  Clear

• Nominal current(A)

  • 32

  Clear

• Nominal voltage(V)

  • 500

  Clear

• Min. cross section (flexible)(mm²)

  • 0.08

  Clear

• Max. cross section (flexible)(mm²)

  • 4

  Clear

• Min. cross section (inflexible)(mm²)

  • 0.08

  Clear

• Max. cross section (inflexible)(mm²)

  • 4

  Clear

• AWG (min.)

  • 28

  Clear

• AWG max.

  • 12

  Clear

• No. of rows

  • 1

  Clear

• Pins per row

  • 1

  Clear

• Weight(g)

  • 2.613
  • 3.351
  • 3.401

  Clear

• Compatible with series (Wago)

  • 769

  Clear

• Colour

  • Green-yellow
  • Grey

  Clear

• Connector type (category)

  • Terminal

  Clear

• Accessory type (serial terminals)

  • Edge connector
  • Front end unit

  Clear

• Configuration

  • Terre

  Clear

• Connection (components)

  • Pull spring
  • Spring-loaded terminal

  Clear
