Stackable 2-conductor PCB terminal block, with fuse mounting【200 Pieces Per Package】
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| 742-161 |
| 742-166 |
| Part Number | Related to |
Standard Unit Price
| Number of pc(s). included in pkg. | Minimum order quantity | Volume Discount | Color | Contact spacing (mm) | Product size (length) (mm) | |
|---|---|---|---|---|---|---|---|---|---|
562.97 € | 200 Pieces Per Package | 1 pack | Available | 26 Days | Grey | 5 | 5.00 | ||
562.97 € | 200 Pieces Per Package | 1 pack | Available | 26 Days | Orange | 5.08 | 5.08 |
Loading...
Basic information
| Number of pins(Pole) | 1 | AWG max. | 12 | AWG (min.) | 28 |
|---|---|---|---|---|---|
| Max. cross section (inflexible)(mm²) | 2.50 | Min. cross section (inflexible)(mm²) | 0.08 | Max. cross section (flexible)(mm²) | 2.50 |
| Min. cross section (flexible)(mm²) | 0.08 | Min. stripping length(mm) | 8 | Stripping length (max.)(mm) | 7 |
| No. of rows | 1 | Pins per row | 1 | Nominal voltage(V) | 320 |
| Product size (height)(mm) | 27.20 | Product size (width)(mm) | 43.5 | Series (connectors) | 742 |
| Connection (components) | PCB terminal features | + CAGE CLAMP® | PCB terminal type (category) | Spring-loaded terminal | |
| Connector orientation | Perpendicular (to the PCB) | Contact material | Cathode copper | Contact surface | Tin plated |
| Industrial goods | Yes | Wire protection | Yes |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
