Power terminal block EK【10 Pieces Per Package】
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
0401023
Basic information
| Color | Silver | AWG | 18 - 2 | Clamp width(mm) | 12 |
|---|---|---|---|---|---|
| Connector cross section (fixed)(mm²) | 0.75 - 35 | Connector cross-section (flexible)(mm²) | 0.75 - 35 | Nominal current(A) | 125 |
| Product size (length)(mm) | 40 | Product size (width)(mm) | 12 | Stripping length(mm) | 14(max.) |
| Connection (components) | Screws | Connector type (category) | Feeder terminal | Industrial goods | Yes |
This page is Power terminal block EK, part number 0401023.
You can find the detail information about specifications and dimensions on part number 0401023.
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
