Protective conductor double-level terminal block PTTBS 2,5
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| 3209620 |
| 3209621 |
| Part Number | Related to |
Standard Unit Price
| Minimum order quantity | Volume Discount | Total number of pins (Pole) | Color | AWG | Connector cross-section (flexible) (mm²) | Product size (height) (mm) | Product size (width) (mm) | Stripping length (mm) | Connection (components) | Insulation material | Industrial goods | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
6.12 € | 50 | 7 Days | 4 | Green-yellow | 26 - 14 | 0.14 - 2.5 | 55 | 5.2 | 8-10 | Quick-connect | PA | Yes | |||
4.14 € | 50 | 7 Days | - | Black | - | 0.14 - 2.50 | 54.5 | - | - | - | - | - |
Loading...
Basic information
| Clamp width(mm) | 5.2 | Connector cross section (fixed)(mm²) | 0.14 - 4 | No. of rows | 2 |
|---|---|---|---|---|---|
| Product size (length)(mm) | 78 | Flammability rating | V0 | Connector type (category) | Dualport PG terminal |
Configure
Basic Attributes
-
Total number of pins(Pole)
-
Color
- Black
- Green-yellow
-
AWG
-
Connector cross-section (flexible)(mm²)
-
Product size (height)(mm)
-
Product size (width)(mm)
-
Stripping length(mm)
-
Connection (components)
-
Insulation material
- PA
-
Industrial goods
- Yes
Filter by standard shipping days
-
- All
- 7 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
