Ground modular terminal block BSLK【10 Pieces Per Package】
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
0810012
Basic information
| Color | Silver | AWG | 20 - 6 | Clamp width(mm) | 8 |
|---|---|---|---|---|---|
| Connector cross section (fixed)(mm²) | 0.5 - 16 | Connector cross-section (flexible)(mm²) | 0.5 - 10 | Nominal current(A) | 82 |
| No. of rows | 1 | Product size (width)(mm) | 8 | Stripping length(mm) | 7(max.) |
| Flammability rating | V0 | Connection (components) | Screws | Connector type (category) | Tripleport PG terminal |
| Industrial goods | Yes |
This page is Ground modular terminal block BSLK, part number 0810012.
You can find the detail information about specifications and dimensions on part number 0810012.
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
