Contact module with 2 contact elements
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| 3SU14001AA101EA0 |
| 3SU14001AA101NA0 |
| 3SU14001AA101PA0 |
| 3SU14001AA101QA0 |
| 3SU14001AA101RA0 |
| 3SU14001AA103EA0 |
| 3SU14001AA103NA0 |
| 3SU14001AA103PA0 |
| 3SU14001AA103QA0 |
| 3SU14001AA103RA0 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Product size (height) (mm) | Ambient temperature (min.) (°C) | Ambient temperature (max.) (°C) | Dielectric strength (kV) | Durability | Electrical lifespan | Contact type | Auxiliary contact type | Switching current (max.) (A) | IP rating | Connection (components) | Mounting type (relays) | Type (misc.) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
17.99 € | 1 | Available | 3 Days | 34 | - | - | 6 | 10000000 | 10000000 | 2 breakers | - | 10 | IP20, IP40 | Screw terminals | Front panel fixed | With 2 contacts | |
30.00 € | 1 | Available | 11 Days | 34 | - | - | 6 | 10000000 | 10000000 | 2 makers | - | 10 | IP20, IP40 | Screw terminals | Front panel fixed | With 2 contacts | |
27.85 € | 1 | Available | 11 Days | 34 | - | - | 6 | 10000000 | 10000000 | 2 breakers | - | 10 | IP20, IP40 | Screw terminals | Front panel fixed | With 2 contacts | |
23.45 € | 1 | Available | 11 Days | 34 | - | - | 6 | 10000000 | 10000000 | 1 maker, 1 breaker | - | 10 | IP20, IP40 | Screw terminals | Front panel fixed | With 2 contacts | |
28.93 € | 1 | Available | 11 Days | 34 | - | - | 6 | 10000000 | 10000000 | 1 maker, 1 breaker | - | 10 | IP20, IP40 | Screw terminals | Front panel fixed | With 2 contacts | |
20.52 € | 1 | Available | 11 Days | 36 | - | - | 6 | 10000000 | 10000000 | 2 breakers | - | 10 | IP20, IP40 | Spring-loaded terminal | Front panel fixed | With 2 contacts | |
33.21 € | 1 | Available | 11 Days | 36 | - | - | 6 | 10000000 | 10000000 | 2 makers | - | 10 | IP20, IP40 | Spring-loaded terminal | Front panel fixed | With 2 contacts | |
33.21 € | 1 | Available | 11 Days | 36 | - | - | 6 | 10000000 | 10000000 | 2 breakers | - | 10 | IP20, IP40 | Spring-loaded terminal | Front panel fixed | With 2 contacts | |
30.00 € | 1 | Available | 11 Days | 36 | - | - | 6 | 10000000 | 10000000 | 1 maker, 1 breaker | - | 10 | IP20, IP40 | Spring-loaded terminal | Front panel fixed | With 2 contacts | |
33.21 € | 1 | Available | 11 Days | 36 | -25 | +70 | - | - | - | - | 1 maker, 1 breaker | - | - | - | - | - |
Loading...
Basic information
| Product size (width)(mm) | 9.8 | Product size (depth)(mm) | 49.7 | Product type | Contact module |
|---|
Configure
Basic Attributes
-
Product size (height)(mm)
-
Ambient temperature (min.)(°C)
-
Ambient temperature (max.)(°C)
- +70
-
Dielectric strength(kV)
- 6
-
Durability
-
Electrical lifespan
- 10000000
-
Contact type
-
Auxiliary contact type
-
Switching current (max.)(A)
-
IP rating
-
Connection (components)
-
Mounting type (relays)
- Front panel fixed
-
Type (misc.)
- With 2 contacts
Filter by standard shipping days
-
- All
- 3 Days or Less
- 11 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
