Circuit breaker 3VA1 IEC frame 100 Switching capacity class B
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
3VA10102ED360AA0
Basic information
| Number of pins | 3-pin | Mounting type (relays) | Fixed | Product size (height)(mm) | 130 |
|---|---|---|---|---|---|
| Product size (width)(mm) | 76.2 | Product size (depth)(mm) | 70 | Adjustment range (amperage) | 100 - 100 A |
| Min. temperature(°C) | -25 | Max. temperature(°C) | +70 | Switching voltage (max.)(V DC/AC) | 690 |
| IP rating | IP40 | OCR type | TM210 | Breaking capacity rating | B |
| Connection (components) | Clamp |
This page is Circuit breaker 3VA1 IEC frame 100 Switching capacity class B, part number 3VA10102ED360AA0.
You can find the detail information about specifications and dimensions on part number 3VA10102ED360AA0.
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
