Circuit breaker 3VA5 UL frame 250 breaking capacity class M
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Number of pins | Adjustment range (amperage) | Switching voltage (max.) (V DC/AC) | OCR type | |
|---|---|---|---|---|---|---|---|---|
722.69 € | 1 | 17 Days | 3-pin | 110 - 110 A | 690 | TM230 | ||
704.76 € | 1 | 17 Days | 3-pin | 110 - 110 A | 690 | TM210 | ||
621.85 € | 1 | 98 Days | 2-pin | 110 - 110 A | 690 | TM210 | ||
789.92 € | 1 | 98 Days | 3-pin | 125 - 125 A | 480 | TM230 | ||
722.69 € | 1 | 16 Days | 3-pin | 125 - 125 A | 690 | TM210 | ||
778.71 € | 1 | 98 Days | 3-pin | 125 - 125 A | 480 | TM210 | ||
621.85 € | 1 | 98 Days | 2-pin | 125 - 125 A | 690 | TM210 | ||
828.01 € | 1 | 17 Days | 3-pin | 150 - 150 A | 690 | TM230 | ||
861.63 € | 1 | 98 Days | 3-pin | 150 - 150 A | 480 | TM230 | ||
850.43 € | 1 | 17 Days | 3-pin | 175 - 175 A | 690 | TM230 | ||
745.09 € | 1 | 98 Days | 2-pin | 175 - 175 A | 690 | TM230 | ||
834.73 € | 1 | 16 Days | 3-pin | 175 - 175 A | 690 | TM210 | ||
917.65 € | 1 | 98 Days | 3-pin | 175 - 175 A | 480 | TM210 | ||
727.17 € | 1 | 17 Days | 2-pin | 175 - 175 A | 690 | TM210 | ||
745.09 € | 1 | 17 Days | 2-pin | 200 A (max) | 690 | TM230 | ||
789.92 € | 1 | 17 Days | 3-pin | 200 A (max) | 690 | TM210 | ||
913.16 € | 1 | 98 Days | 3-pin | 200 A (max) | 480 | TM210 | ||
727.17 € | 1 | 16 Days | 2-pin | 200 A (max) | 690 | TM210 | ||
1,058.83 € | 1 | 4 Days | 3-pin | 225 - 225 A | 480 | TM230 | ||
957.99 € | 1 | 17 Days | 3-pin | 225 - 225 A | 690 | TM210 | ||
823.53 € | 1 | 98 Days | 2-pin | 225 - 225 A | 690 | TM210 | ||
973.67 € | 1 | 17 Days | 3-pin | 250 - 250 A | 690 | TM230 | ||
1,058.83 € | 1 | 98 Days | 3-pin | 250 - 250 A | 480 | TM230 | ||
845.93 € | 1 | 98 Days | 2-pin | 250 - 250 A | 690 | TM230 | ||
1,025.21 € | 1 | 98 Days | 3-pin | 250 - 250 A | 480 | TM210 | ||
823.53 € | 1 | 16 Days | 2-pin | 250 - 250 A | 690 | TM210 |
Loading...
Basic information
| Mounting type (relays) | Fixed | Product size (height)(mm) | 185 | Product size (width)(mm) | 105 |
|---|---|---|---|---|---|
| Product size (depth)(mm) | 83 | Min. temperature(°C) | -25 | Max. temperature(°C) | +70 |
| IP rating | IP40 | Breaking capacity rating | M |
Configure
Basic Attributes
-
Number of pins
- 2-pin
- 3-pin
-
Adjustment range (amperage)
-
Switching voltage (max.)(V DC/AC)
-
OCR type
Filter by standard shipping days
-
- All
- 4 Days or Less
- 16 Days or Less
- 17 Days or Less
- 98 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
