Circuit-breaker, 4p, 400A
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| NZMH3-4-A400 |
| NZMH3-4-AE400 |
| NZMH3-4-AE400-T |
| NZMH3-4-VE400 |
| NZML3-4-VE400 |
| NZMN3-4-AE400-T |
| Part Number | Related to |
Standard Unit Price
| Minimum order quantity | Volume Discount | Rated short-circuit breaking capacity lcu at 400 V, 50 Hz (kA) | Adjustment range short-term delayed short-circuit release (A) | Overload release current setting (A) | Integrated earth fault protection | Adjustment range undelayed short-circuit release (A) | |
|---|---|---|---|---|---|---|---|---|---|---|
2,936.70 € | 1 | 20 Days | 150 | 0|0 | 320|400 | false | 6|10 | |||
3,172.86 € | 1 | 23 Days | 150 | 0|0 | 200|400 | false | 800|4400 | |||
| - | 3,681.11 € | 1 | 25 Days | 150 | 0|0 | 200|400 | true | 800|4400 | ||
3,561.38 € | 1 | 25 Days | 150 | 400|4000 | 200|400 | false | 800|4400 | |||
3,875.96 € | 1 | 25 Days | 150 | 400|4000 | 200|400 | false | 800|4400 | |||
3,063.48 € | 1 | 21 Days | 50 | 0|0 | 200|400 | true | 800|4400 |
Loading...
Basic information
| Number of auxiliary contacts as change-over contact | 0 | Number of auxiliary contacts as normally open contact | 0 | Number of auxiliary contacts as normally closed contact | 0 |
|---|---|---|---|---|---|
| Rated permanent current Iu(A) | 400 | Number of poles | 4 | Rated voltage(V) | 690|690 |
| Degree of protection (IP) | IP20 | Position of connection for main current circuit | Front side | Motor drive integrated | false |
| Type of electrical connection of main circuit | Screw connection | Type of control element | Rocker lever | With switched-off indicator | false |
| Suitable for DIN rail (top hat rail) mounting | false | Motor drive optional | true | With under voltage release | false |
| Device construction | Built-in device fixed built-in technique | DIN rail (top hat rail) mounting optional | false | Complete device with protection unit | true |
Configure
Basic Attributes
-
Rated short-circuit breaking capacity lcu at 400 V, 50 Hz(kA)
-
Adjustment range short-term delayed short-circuit release(A)
-
Overload release current setting(A)
-
Integrated earth fault protection
-
Adjustment range undelayed short-circuit release(A)
-
Type
Filter by standard shipping days
-
- All
- 20 Days or Less
- 21 Days or Less
- 23 Days or Less
- 25 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
