Klauke 16505 Ring terminal Cross section (max.)=6 mm² Hole Ø=5.3 mm Not in
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
16505
Basic information
| Colour | Metal | Contact material | Cathode copper. tin plated | Cross-section range | 4 - 6 mm² |
|---|---|---|---|---|---|
| Cross section (max.)(mm²) | 6 | Hole Ø(mm) | 5.3 | Insulation type | Not insulated |
| Manufacturer part # | 16505 | Material (details) | Cu-ETP. tin-plated | Min. cross section(mm²) | 4 |
| Product type | Ring terminal | Support sleeve | No | Thread size | M5 |
| Type (manufacturer type) | 16505 |
This page is Klauke 16505 Ring terminal Cross section (max.)=6 mm² Hole Ø=5.3 mm Not in, part number 16505.
You can find the detail information about specifications and dimensions on part number 16505.
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
