SSR
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
34.81.7.005.9024
Basic information
| Dimension height(mm) | 15.5 | Dimension width(mm) | 5 | Ambient temperature(°C) | -20 - +60 |
|---|---|---|---|---|---|
| Contact type | 1 maker|SPST-NO | Control voltage range | 3.5 - 12 V DC | Control voltage (min.)(V DC) | 3.5 |
| Control voltage (max.)(V DC) | 12 | Dielectric strength(V) | 2500 | Max. temperature(°C) | +60 |
| Min. temperature(°C) | -20 | Product size (length)(mm) | 28 | Product type | SSR |
| Switching current(A) | 2 | Switching voltage (max.)(V DC) | 33 | Switching voltage (min.)(V DC) | 1.5 |
| Type (manufacturer type) | 34.81.7.005.9024 | Type (misc.) | SSR: | Control current (max.)(mA) | 7 |
| Current load(A) | 2 | Nominal control voltage(V DC) | 5 | Permanent current (max.)(A) | 2 |
| Switching type (relays) | Random turn on |
This page is SSR, part number 34.81.7.005.9024.
You can find the detail information about specifications and dimensions on part number 34.81.7.005.9024.
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
