Pin strip (standard)

Catalog

Part number:

Still undefined. 55 possible part numbers found.

Part number list
Catalog

Part number list

Number of items

Part number

Connection (components)

Connector orientation

Connector type

Connectors

Contact material

Contact spacing

(mm)

Contact surface

Manufacturer part #

Max. temperature

(°C)

Min. temperature

(°C)

Nominal current

(A)

Nominal voltage

(V AC)

No. of rows

Pin length (PCB)

(mm)

Pin length (receptacle)

(mm)

Pin shape

Pins per row

Product size (height)

(mm)

Total number of pins

Type (manufacturer type)

Minimum order quantity

Print\|Soldering	-	Pin strip. straight	-	Copper alloy	1.27	Gold plated	TC-2506246	-	-	1	200	1	3	3	Square	2	8	2	TC-2506246	1 pieces
Print\|Soldering	-	Pin strip. straight	-	Copper alloy	1.27	Gold plated	TC-2506250	-	-	1	200	1	3	3	Square	6	8	6	TC-2506250	1 pieces
Print\|Soldering	-	Pin strip. straight	-	Copper alloy	1.27	Gold plated	TC-2506251	-	-	1	200	1	3	3	Square	8	8	8	TC-2506251	1 pieces
Print\|Soldering	-	Pin strip. straight	-	Copper alloy	1.27	Gold plated	TC-2506252	-	-	1	200	1	3	3	Square	12	8	12	TC-2506252	1 pieces
Print\|Soldering	-	Pin strip. straight	-	Copper alloy	1.27	Gold plated	TC-2506253	-	-	1	200	1	3	3	Square	14	8	14	TC-2506253	1 pieces
Print\|Soldering	-	Pin strip. straight	-	Copper alloy	1.27	Gold plated	TC-2506254	-	-	1	200	1	3	3	Square	16	8	16	TC-2506254	1 pieces
Print\|Soldering	-	Pin strip. straight	-	Copper alloy	1.27	Gold plated	TC-2506255	-	-	1	200	1	3	3	Square	20	8	20	TC-2506255	1 pieces
Print\|Soldering	-	Pin strip. straight	-	Copper alloy	1.27	Gold plated	TC-2506256	-	-	1	200	2	3	3	Square	2	8	4	TC-2506256	1 pieces
Print\|Soldering	-	Pin strip. straight	-	Copper alloy	1.27	Gold plated	TC-2506258	-	-	1	200	2	3	3	Square	4	8	8	TC-2506258	1 pieces
Print\|Soldering	-	Pin strip. straight	-	Copper alloy	1.27	Gold plated	TC-2506259	-	-	1	200	2	3	3	Square	5	8	10	TC-2506259	1 pieces
Print\|Soldering	-	Pin strip. straight	-	Copper alloy	1.27	Gold plated	TC-2506260	-	-	1	200	2	3	3	Square	6	8	12	TC-2506260	1 pieces
Print\|Soldering	-	Pin strip. straight	-	Copper alloy	1.27	Gold plated	TC-2506261	-	-	1	200	2	3	3	Square	7	8	14	TC-2506261	1 pieces
Print\|Soldering	-	Pin strip. straight	-	Copper alloy	1.27	Gold plated	TC-2506262	-	-	1	200	2	3	3	Square	8	8	16	TC-2506262	1 pieces
Print\|Soldering	-	Pin strip. straight	-	Copper alloy	1.27	Gold plated	TC-2506263	-	-	1	200	2	3	3	Square	16	8	32	TC-2506263	1 pieces
Print\|Soldering	-	Pin strip. straight	-	Copper alloy	1.27	Gold plated	TC-2506264	-	-	1	200	2	3	3	Square	17	8	34	TC-2506264	1 pieces
Print\|Soldering	-	Pin strip. straight	-	Copper alloy	1.27	Gold plated	TC-2506265	-	-	1	200	2	3	3	Square	18	8	36	TC-2506265	1 pieces
Print\|Soldering	-	Pin strip. straight	-	Copper alloy	1.27	Gold plated	TC-2506266	-	-	1	200	2	3	3	Square	20	8	40	TC-2506266	1 pieces
Print\|Soldering	-	Pin strip. straight	-	Copper alloy	2	Gold plated	TC-2506317	-	-	1	-	1	2.70	4	Square	2	8.20	2	TC-2506317	1 pieces
Print\|Soldering	-	Pin strip. straight	-	Copper alloy	2	Gold plated	TC-2506318	-	-	1	-	1	2.70	4	Square	3	8.20	3	TC-2506318	1 pieces
Print\|Soldering	-	Pin strip. straight	-	Copper alloy	2	Gold plated	TC-2506321	-	-	1	-	1	2.70	4	Square	6	8.20	6	TC-2506321	1 pieces
Print\|Soldering	-	Pin strip. straight	-	Copper alloy	2	Gold plated	TC-2506322	-	-	1	-	1	2.70	4	Square	8	8.20	8	TC-2506322	1 pieces
Print\|Soldering	-	Pin strip. straight	-	Copper alloy	2	Gold plated	TC-2506323	-	-	1	-	1	2.70	4	Square	10	8.20	10	TC-2506323	1 pieces
Print\|Soldering	-	Pin strip. straight	-	Copper alloy	2	Gold plated	TC-2506324	-	-	1	-	1	2.70	4	Square	12	8.20	12	TC-2506324	1 pieces
Print\|Soldering	-	Pin strip. straight	-	Copper alloy	2	Gold plated	TC-2506327	-	-	1	-	1	2.70	4	Square	20	8.20	20	TC-2506327	1 pieces
Print\|Soldering	-	Pin strip. straight	-	Copper alloy	2	Gold plated	TC-2506328	-	-	-	-	2	2.70	4	Square	2	8.20	4	TC-2506328	1 pieces
Print\|Soldering	-	Pin strip. straight	-	Copper alloy	2	Gold plated	TC-2506329	-	-	-	-	2	2.70	4	Square	3	8.20	6	TC-2506329	1 pieces
Print\|Soldering	-	Pin strip. straight	-	Copper alloy	2	Gold plated	TC-2506330	-	-	-	-	2	2.70	4	Square	4	8.20	8	TC-2506330	1 pieces
Print\|Soldering	-	Pin strip. straight	-	Copper alloy	2	Gold plated	TC-2506331	-	-	-	-	2	2.70	4	Square	5	8.20	10	TC-2506331	1 pieces
Print\|Soldering	-	Pin strip. straight	-	Copper alloy	2	Gold plated	TC-2506332	-	-	-	-	2	2.70	4	Square	6	8.20	12	TC-2506332	1 pieces
Print\|Soldering	-	Pin strip. straight	-	Copper alloy	2	Gold plated	TC-2506333	-	-	-	-	2	2.70	4	Square	7	8.20	14	TC-2506333	1 pieces
Print\|Soldering	-	Pin strip. straight	-	Copper alloy	2	Gold plated	TC-2506334	-	-	-	-	2	2.70	4	Square	8	8.20	16	TC-2506334	1 pieces
Print\|Soldering	-	Pin strip. straight	-	Copper alloy	2	Gold plated	TC-2506335	-	-	-	-	2	2.70	4	Square	10	8.20	20	TC-2506335	1 pieces
Print\|Soldering	-	Pin strip. straight	-	Copper alloy	2	Gold plated	TC-2506336	-	-	-	-	2	2.70	4	Square	15	8.20	30	TC-2506336	1 pieces
Print\|Soldering	-	Pin strip. straight	-	Copper alloy	2	Gold plated	TC-2506338	-	-	-	-	2	2.70	4	Square	17	8.20	34	TC-2506338	1 pieces
Print\|Soldering	-	Pin strip. straight	-	Copper alloy	2	Gold plated	TC-2506339	-	-	-	-	2	2.70	4	Square	18	8.20	36	TC-2506339	1 pieces
Print\|Soldering	-	Pin strip. straight	-	Copper alloy	2	Gold plated	TC-2506340	-	-	-	-	2	2.70	4	Square	20	8.20	40	TC-2506340	1 pieces
Print\|Soldering	-	Pin strip. straight	-	-	2.54	-	TC-2506377	-	-	3	-	1	2.50	-	Square	2	10.80	2	TC-2506377	1 pieces
Print\|Soldering	-	Pin strip. straight	-	-	2.54	-	TC-2506378	-	-	3	-	1	2.50	-	Square	6	10.80	6	TC-2506378	1 pieces
Print\|Soldering	-	Pin strip. straight	-	-	2.54	-	TC-2506379	-	-	3	-	1	2.50	-	Square	12	10.80	12	TC-2506379	1 pieces
Print\|Soldering	-	Pin strip. straight	-	-	2.54	-	TC-2506380	-	-	3	-	1	2.50	-	Square	14	10.80	14	TC-2506380	1 pieces
Print\|Soldering	-	Pin strip. straight	-	-	2.54	-	TC-2506381	-	-	3	-	1	2.50	-	Square	16	10.80	16	TC-2506381	1 pieces
Print\|Soldering	-	Pin strip. straight	-	-	2.54	-	TC-2506382	-	-	3	-	1	2.50	-	Square	2	11.6	2	TC-2506382	1 pieces
Print\|Soldering	-	Pin strip. straight	-	-	2.54	-	TC-2506385	-	-	3	-	1	2.50	-	Square	14	11.6	14	TC-2506385	1 pieces
Print\|Soldering	-	Pin strip. straight	-	-	2.54	-	TC-2506386	-	-	3	-	1	2.50	-	Square	16	11.6	16	TC-2506386	1 pieces
Print\|Soldering	-	Pin strip. straight	-	-	2.54	-	TC-2506387	-	-	3	-	1	3.30	-	Square	2	12.60	2	TC-2506387	1 pieces
Print\|Soldering	-	Pin strip. straight	-	-	2.54	-	TC-2506388	-	-	3	-	1	3.30	-	Square	6	12.60	6	TC-2506388	1 pieces
Print\|Soldering	-	Pin strip. straight	-	-	2.54	-	TC-2506389	-	-	3	-	1	3.30	-	Square	12	12.60	12	TC-2506389	1 pieces
Print\|Soldering	-	Pin strip. straight	-	-	2.54	-	TC-2506390	-	-	3	-	1	3.30	-	Square	14	12.60	14	TC-2506390	1 pieces
Print\|Soldering	-	Pin strip. straight	-	-	2.54	-	TC-2506391	-	-	3	-	1	3.30	-	Square	16	12.60	16	TC-2506391	1 pieces
Print	Perpendicular (to the PCB)	Pin strip. straight	wire-to-board	-	2.50	-	TC-2506395	-	-	-	-	1	-	-	-	6	-	6	TC-2506395	1 pieces
Print\|Soldering	-	Pin strip. right angle	-	Copper alloy	2.54	-	TC-2506396	+105	-40	3	-	1	3.30	4.50	Square	2	-	2	TC-2506396	1 pieces
Print\|Soldering	-	Pin strip. right angle	-	Copper alloy	2.54	-	TC-2506398	+105	-40	3	-	1	3.30	4.50	Square	6	-	6	TC-2506398	1 pieces
Print\|Soldering	-	Pin strip. right angle	-	Copper alloy	2.54	-	TC-2506399	+105	-40	3	-	1	3.30	4.50	Square	12	-	12	TC-2506399	1 pieces
Print\|Soldering	-	Pin strip. right angle	-	Copper alloy	2.54	-	TC-2506400	+105	-40	3	-	1	3.30	4.50	Square	14	-	14	TC-2506400	1 pieces
Print\|Soldering	-	Pin strip. right angle	-	Copper alloy	2.54	-	TC-2506401	+105	-40	3	-	1	3.30	4.50	Square	16	-	16	TC-2506401	1 pieces

Unit price (excluding VAT)(Unit price including VAT)	Standard shipping days

0.47 € ( 0.56 € )	3 working days
0.65 € ( 0.77 € )	3 working days
0.71 € ( 0.84 € )	3 working days
0.79 € ( 0.94 € )	3 working days
0.88 € ( 1.05 € )	3 working days
1.33 € ( 1.58 € )	3 working days
1.33 € ( 1.58 € )	3 working days
0.87 € ( 1.04 € )	3 working days
0.97 € ( 1.15 € )	3 working days
1.01 € ( 1.20 € )	3 working days
1.33 € ( 1.58 € )	3 working days
1.33 € ( 1.58 € )	3 working days
1.33 € ( 1.58 € )	3 working days
1.53 € ( 1.82 € )	3 working days
1.85 € ( 2.20 € )	3 working days
1.85 € ( 2.20 € )	3 working days
2.05 € ( 2.44 € )	3 working days
0.29 € ( 0.35 € )	3 working days
0.33 € ( 0.39 € )	3 working days
0.52 € ( 0.62 € )	3 working days
0.56 € ( 0.67 € )	3 working days
0.63 € ( 0.75 € )	3 working days
0.67 € ( 0.80 € )	3 working days
0.77 € ( 0.92 € )	3 working days
0.36 € ( 0.43 € )	3 working days
0.52 € ( 0.62 € )	74 working days
0.39 € ( 0.46 € )	98 working days
0.44 € ( 0.52 € )	3 working days
0.56 € ( 0.67 € )	3 working days
0.61 € ( 0.73 € )	3 working days
0.71 € ( 0.84 € )	3 working days
0.75 € ( 0.89 € )	3 working days
0.92 € ( 1.09 € )	3 working days
1.33 € ( 1.58 € )	3 working days
1.33 € ( 1.58 € )	3 working days
1.53 € ( 1.82 € )	3 working days
0.27 € ( 0.32 € )	3 working days
0.33 € ( 0.39 € )	3 working days
0.35 € ( 0.42 € )	3 working days
0.49 € ( 0.58 € )	3 working days
0.40 € ( 0.48 € )	3 working days
0.24 € ( 0.29 € )	3 working days
0.44 € ( 0.52 € )	3 working days
0.39 € ( 0.46 € )	3 working days
0.24 € ( 0.29 € )	3 working days
0.32 € ( 0.38 € )	3 working days
0.36 € ( 0.43 € )	3 working days
0.44 € ( 0.52 € )	3 working days
0.52 € ( 0.62 € )	3 working days
0.55 € ( 0.65 € )	3 working days
0.21 € ( 0.25 € )	3 working days
0.44 € ( 0.52 € )	3 working days
0.52 € ( 0.62 € )	3 working days
0.59 € ( 0.70 € )	3 working days
0.65 € ( 0.77 € )	3 working days
