Configure

Calibrated to
- ISO standards
- Manufacturer's standards (no certificate)
Product size (height)(mm)
- 19
- 80
- 190
- 193
Product size (width)(mm)
- 19
- 34
- 38
- 63
- 75
Product size (length)(mm)
- 75
- 148
- 166
Weight(g)
- 28
- 80
- 200
- 514
Accuracy (details)(%)
Accuracy (details)(°C)
- ±0.5
- ±1.5
Accuracy (+/-) °C(°C)
- 0.5
- 1
- 1.5
- 2
Basic accuracy (+/-)(%)
- 0.5
- 1
- 1.5
- 2
Calibration service
- 3 appropriate calibration values in the measuring range of the respective device (-20;0; +60 °C)
- 3 appropriate calibration values in the measuring range of the respective device (-18;0; +60 °C)
Display (thermometer)
- 1:1
- 6:1
- 10:1
- 12:1
- 30:1
- 50:1
Emission level (max.)
- 0.95
- 1
Emission level (min.)
- 0.1
- 0.2
- 0.95
Emissivity
Max. temperature(°C)
- +210
- +250
- +300
- +400
- +600
- +650
- +1500
Min. temperature(°C)
- -30
- -25
- -10
No. of memory units
- 200
Optics
- 1.1
- 6:1
- 10:1
- 12:1
- 30:1
- 50:1
Pick-up time (details)
- 0.5 s
- 0.5 s IR/1.25s NTC
Pick-up time (details)(s)
- 0.5
- < 1
Power supply (details)
Probe thermometer features
- Contact measurement
Product size (depth)(mm)
- 31
- 38
Reading range - temperature(°C)
Response time(s)
- 0.5
Sensor type
- K
- NTC
Temperature resolution(°C)
- 0.1
Type
Est. shipping days
- All
- Within 3 working days
- Within 4 working days
- Within 9 working days
- Within 13 working days

TESTO

IR thermometer

Name: IR thermometer from TESTO | MISUMI
Brand: TESTO
SKU: 222303423427
Availability: Instock

Catalog

Part number:

Still undefined. 13 possible part numbers found.

Part number list
Catalog

Part number list

Number of items

Part number

Order suspended 0560 8311
0560 8312
0560 8314
0560 8316
0560 8351
0560 8352
0560 8353
0563 8051
0563 8282
0563 8284
0563 8312
0563 8314
0563 8315

Calibrated to

Product size (height)

(mm)

Product size (width)

(mm)

Product size (length)

(mm)

Weight

(g)

Accuracy (details)

(%)

Accuracy (details)

(°C)

Accuracy (+/-) °C

(°C)

Basic accuracy (+/-)

(%)

Calibration service

Display (thermometer)

Emission level (max.)

Emission level (min.)

Emissivity

Max. temperature

(°C)

Min. temperature

(°C)

No. of memory units

Optics

Pick-up time (details)

(s)

Power supply (details)

Probe thermometer features

Product size (depth)

(mm)

Reading range - temperature

(°C)

Response time

(s)

Sensor type

Temperature resolution

(°C)

Minimum order quantity

ISO standards	190	38	75	200	-	-	1.5	1.5	3 appropriate calibration values in the measuring range of the respective device (-18;0; +60 °C)	10:1	1	0.2	-	+400	-30	-	10:1	-	-	9 V battery	-	-	-	0.5	-	-	1 pieces
ISO standards	190	38	75	200	±1.5 °C/±1.5	-	1.5	1.5	3 appropriate calibration values in the measuring range of the respective device (-18;0; +60 °C)	12:1	1	0.2	0.2 - 1.0	+400	-30	-	12:1	0.5 s	-	9 V battery	Contact measurement	-	-30 to +400	0.5	K	-	1 pieces
ISO standards	190	38	75	200	±1 °C/±1	-	1	1	3 appropriate calibration values in the measuring range of the respective device (-18;0; +60 °C)	30:1	1	0.2	0.2 - 1.0	+400	-30	-	30:1	0.5 s	-	9 V battery	Contact measurement	-	-30 to +400	0.5	K	-	1 pieces
ISO standards	190	75	-	200	± 1.5°C/1.5	-	1.5	1.5	3 appropriate calibration values in the measuring range of the respective device (-18;0; +60 °C)	30:1	1	0.2	2 -1.0	+210	-30	-	30:1	-	0.5	9 V battery	-	38	-30 to + 210	-	-	0.1	1 pieces
ISO standards	193	63	166	514	±1 °C/±1	-	1	1	3 appropriate calibration values in the measuring range of the respective device (-18;0; +60 °C)	50:1	1	0.1	0.10 - 1.00	+650	-30	200	50:1	0.5 s	-	3 batteries Type AA. USB	Contact measurement	-	-30 bis +600	0.5	K	-	1 pieces
-	193	63	166	514	±1 °C/±1	-	2	1	-	50:1	1	0.1	0.10 - 1.00	+1500	-10	200	50:1	0.5 s	-	3 batteries Type AA. USB	Contact measurement	-	-30 bis +600	0.5	K	-	1 pieces
-	193	63	166	514	±1 °C/±1	-	1	1	-	50:1	1	0.1	0.10 - 1.00	+600	-30	200	50:1	0.5 s	-	3 batteries Type AA. USB	Contact measurement	-	-30 bis +600	0.5	K	-	1 pieces
Manufacturer's standards (no certificate)	80	19	-	28	± 2	-	2	2	3 appropriate calibration values in the measuring range of the respective device (-20;0; +60 °C)	1:1	0.95	0.95	0.95 (fixed)	+250	-25	-	1.1	-	< 1	LR-44 battery	-	31	-25 to +250	-	-	-	1 pieces
ISO standards	19	34	148	80	-	±1.5	1.5	1.5	3 appropriate calibration values in the measuring range of the respective device (-18;0; +60 °C)	6:1	1	0.1	0.95 - 1.0	+300	-30	-	6:1	-	0.5	2x AAA battery	-	-	-50 to +300	-	-	0.1	1 pieces
-	19	34	148	80	-	±0.5	0.5	0.5	-	6:1	1	0.1	0.95 - 1.0	+300	-30	-	6:1	0.5 s IR/1.25s NTC	-	2x AAA battery	Contact measurement	-	-50 to +300	-	NTC	-	1 pieces
Manufacturer's standards (no certificate)	190	38	75	200	-	-	1.5	1.5	-	12:1	1	0.2	-	+400	-30	-	12:1	-	-	9 V battery	Contact measurement	-	-	0.5	K	-	1 pieces
Manufacturer's standards (no certificate)	190	38	75	200	-	-	1	1	-	30:1	1	0.2	-	+400	-30	-	30:1	-	-	9 V battery	Contact measurement	-	-	0.5	K	-	1 pieces
-	190	75	-	200	± 1.5°C/1.5	-	1.5	1.5	-	30:1	1	0.2	2 -1.0	+210	-30	-	30:1	-	0.5	9 V battery	Contact measurement	38	-30 to + 210	-	K	-	1 pieces

Unit price (excluding VAT)(Unit price including VAT)	Standard shipping days

222.36 € ( 264.61 € )	9 working days
255.17 € ( 303.65 € )	9 working days
319.67 € ( 380.41 € )	9 working days
319.67 € ( 380.41 € )	9 working days
449.75 € ( 535.20 € )	9 working days
646.05 € ( 768.80 € )	3 working days
486.44 € ( 578.86 € )	13 working days
79.53 € ( 94.64 € )	3 working days
270.48 € ( 321.87 € )	9 working days
225.19 € ( 267.98 € )	3 working days
244.87 € ( 291.40 € )	3 working days
307.17 € ( 365.53 € )	3 working days
225.19 € ( 267.98 € )	4 working days
