Pin Strip (standard)
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| TC-048612-002-1-00 |
| TC-048612-004-1-00 |
| TC-048612-020-1-00 |
| TC-0628-100-008-00 |
| TC-0628-100-040-00 |
| TC-1414-14-1-20-00 |
| TC-1468-16,5-40-10-00 |
| TC-18884-13-040-00 |
| TC-18947-13-008-00 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Case material | Colour | Connection (components) | Connector orientation | Connector type | Contact spacing (mm) | Manufacturer part # | Max. temperature (°C) | Nominal current (A) | Nominal voltage (V) | Nominal voltage (V AC) | Nominal voltage (V DC) | No. of rows | Pin diameter (mm) | Pin length (PCB) (mm) | Pin length (receptacle) (mm) | Pins per row | Product size (height) (mm) | Product size (width) (mm) | Product size (length) (mm) | Separable | Total number of pins | Type (manufacturer type) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
0.09 € | 1 | Available | 3 Days | Thermoplastic material | White | Perpendicular (to the PCB) | Pin strip. straight | 2.50 | TC-048612-002-1-00 | +105 | 3 | - | 100 | - | 1 | - | 3.30 | 4.70 | 2 | 2.5 | 5 | 11.30 | No | 2 | TC-048612-002-1-00 | ||
0.25 € | 1 | Available | 3 Days | Thermoplastic material | White | Perpendicular (to the PCB) | Pin strip. straight | 2.50 | TC-048612-004-1-00 | +105 | 3 | - | 100 | - | 1 | - | 3.30 | 4.70 | 4 | 2.5 | 10.00 | 11.30 | No | 4 | TC-048612-004-1-00 | ||
0.87 € | 1 | Available | 3 Days | Thermoplastic material | White | Perpendicular (to the PCB) | Pin strip. straight | 2.50 | TC-048612-020-1-00 | +105 | 3 | - | 100 | - | 1 | - | 3.30 | 4.70 | 20 | 2.5 | 11.30 | 50.00 | No | 20 | TC-048612-020-1-00 | ||
0.21 € | 1 | Available | 3 Days | Thermoplastic UL94V-O | Black | Perpendicular (to the PCB) | Pin strip. straight | 2 | TC-0628-100-008-00 | +125 | 1 | 250 | - | - | 1 | - | 2.80 | 4.40 | 8 | - | - | - | - | 8 | TC-0628-100-008-00 | ||
1.33 € | 1 | Available | 3 Days | Thermoplastic material | Black | Perpendicular (to the PCB) | Pin strip. straight | 2 | TC-0628-100-040-00 | +125 | 1 | - | - | 1000 | 1 | - | 2.80 | 4.40 | 40 | 2.00 | 8.70 | 80.00 | No | 40 | TC-06284-100-40-00 | ||
0.89 € | 1 | Available | 3 Days | Thermoplastic material | Black | SMD | Perpendicular (to the PCB) | Pin strip. straight | 1.27 | TC-1414-14-1-20-00 | +105 | 1 | - | 500 | - | 1 | - | 2.29 | 3.05 | 14 | 2.10 | 6.34 | 17.78 | No | 14 | TC-1414-14-1-20-00 | |
2.57 € | 1 | Available | 3 Days | Thermoplastic material | Black | Perpendicular (to the PCB) | Pin strip. straight | 2 | TC-1468-16.5-40-10-00 | +125 | 1 | - | 250 | - | 1 | 0.80 | 2.80 | 4 | 40 | 2.00 | 16.5 | 80.00 | No | 40 | TC-1468.5-40-10-00 | ||
1.33 € | 1 | Available | 3 Days | Thermoplastic material | Black | Perpendicular (to the PCB) | Pin strip. straight | 2.54 | TC-18884-13-040-00 | +125 | 3 | - | 250 | - | 2 | - | 3.30 | 6.80 | 20 | 5 | 12.60 | 50.8 | No | 40 | TC-18884-13-040-00 | ||
0.16 € | 1 | 3 Days | Thermoplastic material | Black | - | Pin strip. right angle | 2.54 | TC-18947-13-008-00 | +125 | 3 | - | 250 | - | 2 | - | 3.30 | 4.80 | 4 | 8.3 | 10.16 | 11.24 | No | 8 | TC-18947-13-008-00 |
Loading...
Basic information
| Contact material | Copper alloy | Contact surface | Gold plated | Industrial goods | No |
|---|---|---|---|---|---|
| Min. temperature(°C) | -40 | Pin shape | Rectangular | Product type | Pin strip (standard) |
| RoHS-compliant | Yes |
Configure
Basic Attributes
-
Case material
-
Colour
-
Connection (components)
-
Connector orientation
-
Connector type
-
Contact spacing(mm)
-
Manufacturer part #
-
Max. temperature(°C)
-
Nominal current(A)
-
Nominal voltage(V)
-
Nominal voltage(V AC)
-
Nominal voltage(V DC)
-
No. of rows
-
Pin diameter(mm)
-
Pin length (PCB)(mm)
-
Pin length (receptacle)(mm)
-
Pins per row
-
Product size (height)(mm)
-
Product size (width)(mm)
-
Product size (length)(mm)
-
Separable
-
Total number of pins
-
Type (manufacturer type)
Filter by standard shipping days
-
- All
- 3 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
