Configure

Clamp Range A(mm)
B(mm)
- 39
- 48.5
- 56
- 57
- 58.5
- 59.5
- 71.5
- 72
- 74
- 75
- 75.5
- 76
C(mm)
- 33
- 45
- 75.5
- 85
- 94.5
- 96.6
- 99
- 99.5
- 105.5
- 111.5
- 120
- 123
D(mm)
- 72
- 93.5
- 135
- 143.5
- 151.5
- 155
- 172.5
- 175
- 180.5
- 185.5
- 192
- 194.5
E(mm)
- 20
- 25
- 34
- 42
F(mm)
- 95
- 112
- 151
- 190
G(mm)
- 115
- 137
- 185
- 232
H(mm)
- 38
- 42
- 50
- 65
I(mm)
- 42
- 46
- 55
- 71
J(mm)
- 15
- 16
- 20
- 23
K(mm)
- R13
- R16
- R20
- R25
L(mm)
- 33°
- 34°
- 35°
- 37°
- 39°
- 41°
- 42°
- 43°
- 47°
- 51°
Mass(kg)
- 0.77
- 0.8
- 0.83
- 0.84
- 1.34
- 1.37
- 1.44
- 1.46
- 2.22
- 2.33
- 2.41
- 2.49
- 2.52
- 2.59
- 2.62
- 2.69
- 4.09
- 4.18
- 4.39
- 4.42
- 4.59
- 4.68
- 4.83
- 4.96
Compatible T Groove Width(mm)
- 12
- 14
- 16
- 18
- 20
- 22
- 24
- 26
- 28
- 32
Attached T slot nuts
Bolt Diameter x Length(mm)
Type
- EUC-PN
Est. shipping days
- All
- Within 6 working days
- Within 8 working days

NABEYA

Universal Clamp

Catalog

Part number:

Still undefined. 24 possible part numbers found.

Part number list
More Information
Catalog

Part number list

Number of items

Part number

Clamp Range A

(mm)

Mass

(kg)

Compatible T Groove Width

(mm)

Attached T slot nuts

Bolt Diameter x Length

(mm)

Minimum order quantity

0 - 90	39	33	72	20	95	115	38	42	15	R13	51°	0.83	14	TNM1412	M12x145 (Normal)	1 pieces
0 - 90	39	33	72	20	95	115	38	42	15	R13	51°	0.84	16	TNM1612	M12x145	1 pieces
0 - 90	39	33	72	20	95	115	38	42	15	R13	51°	0.77	12	TNM1210	M10x145	1 pieces
0 - 90	39	33	72	20	95	115	38	42	15	R13	51°	0.8	14	TNM1410	M10x145	1 pieces
0 - 100	48.5	45	93.5	25	112	137	42	46	16	R16	47°	1.44	18	TNM1816	M16x175 (Normal)	1 pieces
0 - 100	48.5	45	93.5	25	112	137	42	46	16	R16	47°	1.46	20	TNM2016	M16x175	1 pieces
0 - 100	48.5	45	93.5	25	112	137	42	46	16	R16	47°	1.37	18	TNM1814	M14x175	1 pieces
0 - 100	48.5	45	93.5	25	112	137	42	46	16	R16	47°	1.34	16	TNM1614	M14x175	1 pieces
0 - 100	56	99	155	34	151	185	50	55	20	R20	33°	2.59	22	TNM2220	M20x200 (Normal)	1 pieces
0 - 100	56	99	155	34	151	185	50	55	20	R20	33°	2.62	24	TNM2420	M20x20	1 pieces
0 - 100	56	99	155	34	151	185	50	55	20	R20	33°	2.69	26	TNM2620	M20x20	1 pieces
0 - 105	57	94.5	151.5	34	151	185	50	55	20	R20	35°	2.41	20	TNM2018	M18x20	1 pieces
0 - 105	57	94.5	151.5	34	151	185	50	55	20	R20	35°	2.49	22	TNM2218	M18x20	1 pieces
0 - 105	57	94.5	151.5	34	151	185	50	55	20	R20	35°	2.52	24	TNM2418	M18x20	1 pieces
0 - 115	58.5	85	143.5	34	151	185	50	55	20	R20	39°	2.33	18	TNM1816	M16x20	1 pieces
0 - 125	59.5	75.5	135	34	151	185	50	55	20	R20	43°	2.22	16	TNM1614	M14x20	1 pieces
0 - 125	71.5	123	194.5	42	190	232	65	71	23	R25	33°	4.83	28	TNM2824	M24x250 (Normal)	1 pieces
0 - 125	71.5	123	194.5	42	190	232	65	71	23	R25	33°	4.96	32	TNM3224	M24x250	1 pieces
0 - 130	72	120	192	42	190	232	65	71	23	R25	34°	4.68	28	TNM2822	M22x250	1 pieces
0 - 140	74	111.5	185.5	42	190	232	65	71	23	R25	37°	4.59	26	TNM2622	M22x250	1 pieces
0 - 140	74	111.5	185.5	42	190	232	65	71	23	R25	37°	4.42	24	TNM2420	M20x250	1 pieces
0 - 145	75	105.5	180.5	42	190	232	65	71	23	R25	39°	4.39	22	TNM2220	M20x250	1 pieces
0 - 150	75.5	99.5	175	42	190	232	65	71	23	R25	41°	4.18	20	TNM2018	M18x250	1 pieces
0 - 155	76	96.6	172.5	42	190	232	65	71	23	R25	42°	4.09	18	TNM1816	M16x250	1 pieces

Unit price (excluding VAT)(Unit price including VAT)	Standard shipping days

106.29 € ( 126.49 € )	6 working days
109.04 € ( 129.76 € )	8 working days
107.07 € ( 127.41 € )	8 working days
107.33 € ( 127.72 € )	6 working days
124.55 € ( 148.21 € )	8 working days
125.58 € ( 149.44 € )	8 working days
125.04 € ( 148.80 € )	8 working days
124.85 € ( 148.57 € )	6 working days
195.76 € ( 232.95 € )	8 working days
200.47 € ( 238.56 € )	8 working days
200.89 € ( 239.06 € )	8 working days
199.21 € ( 237.06 € )	8 working days
199.68 € ( 237.62 € )	8 working days
199.87 € ( 237.85 € )	8 working days
198.72 € ( 236.48 € )	8 working days
198.05 € ( 235.68 € )	8 working days
270.83 € ( 322.29 € )	8 working days
303.29 € ( 360.92 € )	8 working days
275.35 € ( 327.67 € )	6 working days
274.81 € ( 327.02 € )	8 working days
273.79 € ( 325.81 € )	8 working days
273.60 € ( 325.58 € )	8 working days
272.34 € ( 324.08 € )	8 working days
271.80 € ( 323.44 € )	6 working days

More Information

Basic information

Basic information

It can steplessly fasten tall and short workpieces.
