AMF

6348S Parallel supports-set, standard

6348S Parallel supports-set, standard

Part number:

Still undefined. 3 possible part numbers found.
Quantity:

Part number list

Number of items
  • 1
    • Part number
    371096
    371104
    371112

    L

    Pair

    Size

    Weight

    		RoHS?Minimum order quantity
    100
    20
    100
    11kg
    10
    1 pieces
    125
    24
    125
    14kg
    10
    1 pieces
    150
    24
    150
    17kg
    10
    1 pieces
    Unit price (excluding VAT)(Unit price including VAT)
    Standard shipping days
    803.08 €
    ( 955.67 € )
    5 working days
    844.62 €
    ( 1,005.10 € )
    5 working days
    887.31 €
    ( 1,055.90 € )
    5 working days
  • 1

    • More Information

    Basic information

    Parallel supports-set, standard In wooden stand.
    Plain parallel, fine-ground, in pairs.
    Size data on front of product.
    Sets offer a large range with 1 mm graduation.
    Case-hardened.

    Pair tolerance tp at height IT 5.
    Rated dimensional tolerance in height and width to DIN ISO 2768m.
    Remaining dimensions to DIN ISO 2768m. The product is available per 1 peace.
