KNIPEX

High Leverage Combination Pliers / Chrome plated|tempered / DIN ISO 5746

High Leverage Combination Pliers / Chrome plated|tempered / DIN ISO 5746

Part number:

Still undefined. 2 possible part numbers found.
Quantity:

Part number list

Number of items
  • 1
    • Part number
    02 07 200
    02 07 225
    Related

    Overall Length

    (mm)

    DIN standard

    EN standard

    Manufacturer part #

    Range of use (pliers)

    Type

    Weight

    (g)

    Wire hardness (max.)

    (mm²)

    Wire hardness (max.) hard wire

    (mm)

    Wire hardness piano wire (max.)

    (mm)

    		Minimum order quantity

    Data sheet

    200
    DIN ISO 5746|DIN EN 60900
    EN 60900
    02 07 200
    VDE
    02 07 200
    380
    Hard wire: 2.8 mm diameter · Piano wire: 2.2 mm diameter · Max 25
    2.8
    2.2
    1 pieces

    Data sheet

    225
    DIN ISO 5746
    -
    02 07 225
    Workshop
    02 07 225
    486
    Hard wire: 3.0 mm diameter · Piano wire: 2.5 mm diameter · MaxDiameter: 25
    3
    2.5
    1 pieces
    Unit price (excluding VAT)(Unit price including VAT)
    Standard shipping days
    37.59 €
    ( 44.73 € )
    9 working days
    41.94 €
    ( 49.91 € )
    9 working days
  • 1

    • More Information

    Basic information

    [Specifications]
    ・Product type: Kraft comb pliers
    ・Material: Tool steel
    ・Material properties: chrome plated|tempered
    ・Standards: DIN ISO 5746

    [Features]
    ・35% less effort required than with conventional combination pliers
    ・With cutting edges (hardness approx. 63 HRC) for heavy duty
