6 Series / Reversal with Tab / 2 Slots / 8 Holes

CatalogP.2-591

Part number:

Still undefined. 32 possible part numbers found.

Outline drawing and specifications table
Part number list
More Information
Catalog

Outline drawing and specifications table

6 Series/Reversal with Tab/2 Slots/8 Holes:Related Image

Material: EN AC-46100 Equiv.

Specifications

Part Number

HBLFTD6

Part Number	Mass (g)	Applicable Screw, T Nut				Allowable Load (N)	Unit Price	Volume Discount Rate
Type	Mass (g)	Screw	Quantity	T Nut	Quantity	Allowable Load (N)	1~99 pc(s).	100~200
HBLFSDW6	88	CBM6-12	8	HNTT6-6	8	2940
HBLFSDW6-50	53	CBM6-12	8	HNTT6-6	8	2964

Alterations

Part number list

Number of items

Part number

Compatible Extrusion Width

(mm)

Extrusion Size

Cover Mounting Hole Addition Work

Accessories

RoHS?

Minimum order quantity

60 ～ 120	For 30 and 60	Not Provided	Not Provided	10	1 pieces
50 ～ 100	For 50 Sq.	Not Provided	Not Provided	10	1 pieces
50 ～ 100	For 50 Sq.	C (Tap for Cover Mounting)	Not Provided	10	1 pieces
-	For 50 Sq.	C (Tap for Cover Mounting)	SEC (Washer Integrated Screw and Nut Set)	10	1 pieces
-	For 50 Sq.	C (Tap for Cover Mounting)	SEP (Screw, Post-Assembly Insertion Spring Nut Set)	-	1 pieces
-	For 50 Sq.	C (Tap for Cover Mounting)	SET (Screw, Nut Set)	-	1 pieces
-	For 50 Sq.	C (Tap for Cover Mounting)	SEU (Screw, Pre-Assembly Insertion Spring Nut Set)	-	1 pieces
-	For 50 Sq.	C (Tap for Cover Mounting)	SSP (Stainless Steel Screw, Post-Assembly Insertion Spring Nut Set)	10	1 pieces
-	For 50 Sq.	C (Tap for Cover Mounting)	SST (Stainless Steel Screw and Nut Set)	10	1 pieces
-	For 50 Sq.	C (Tap for Cover Mounting)	SSU (Stainless Steel Screw, Pre-Assembly Insertion Spring Nut Set)	10	1 pieces
-	For 50 Sq.	Not Provided	SEC (Washer Integrated Screw and Nut Set)	10	1 pieces
-	For 50 Sq.	Not Provided	SEP (Screw, Post-Assembly Insertion Spring Nut Set)	-	1 pieces
50 ～ 100	For 50 Sq.	Not Provided	SET (Screw, Nut Set)	-	1 pieces
-	For 50 Sq.	Not Provided	SEU (Screw, Pre-Assembly Insertion Spring Nut Set)	-	1 pieces
-	For 50 Sq.	Not Provided	SSP (Stainless Steel Screw, Post-Assembly Insertion Spring Nut Set)	10	1 pieces
50 ～ 100	For 50 Sq.	Not Provided	SST (Stainless Steel Screw and Nut Set)	10	1 pieces
-	For 50 Sq.	Not Provided	SSU (Stainless Steel Screw, Pre-Assembly Insertion Spring Nut Set)	10	1 pieces
60 ～ 120	For 30 and 60	C (Tap for Cover Mounting)	Not Provided	10	1 pieces
-	For 30 and 60	C (Tap for Cover Mounting)	SEC (Washer Integrated Screw and Nut Set)	10	1 pieces
-	For 30 and 60	C (Tap for Cover Mounting)	SEP (Screw, Post-Assembly Insertion Spring Nut Set)	-	1 pieces
-	For 30 and 60	C (Tap for Cover Mounting)	SET (Screw, Nut Set)	-	1 pieces
-	For 30 and 60	C (Tap for Cover Mounting)	SEU (Screw, Pre-Assembly Insertion Spring Nut Set)	-	1 pieces
-	For 30 and 60	C (Tap for Cover Mounting)	SSP (Stainless Steel Screw, Post-Assembly Insertion Spring Nut Set)	-	1 pieces
-	For 30 and 60	C (Tap for Cover Mounting)	SST (Stainless Steel Screw and Nut Set)	-	1 pieces
-	For 30 and 60	C (Tap for Cover Mounting)	SSU (Stainless Steel Screw, Pre-Assembly Insertion Spring Nut Set)	-	1 pieces
-	For 30 and 60	Not Provided	SEC (Washer Integrated Screw and Nut Set)	10	1 pieces
-	For 30 and 60	Not Provided	SEP (Screw, Post-Assembly Insertion Spring Nut Set)	-	1 pieces
60 ～ 120	For 30 and 60	Not Provided	SET (Screw, Nut Set)	-	1 pieces
-	For 30 and 60	Not Provided	SEU (Screw, Pre-Assembly Insertion Spring Nut Set)	-	1 pieces
-	For 30 and 60	Not Provided	SSP (Stainless Steel Screw, Post-Assembly Insertion Spring Nut Set)	-	1 pieces
60 ～ 120	For 30 and 60	Not Provided	SST (Stainless Steel Screw and Nut Set)	-	1 pieces
-	For 30 and 60	Not Provided	SSU (Stainless Steel Screw, Pre-Assembly Insertion Spring Nut Set)	-	1 pieces

Unit price (excluding VAT)(Unit price including VAT)	Standard shipping days

4.27 € ( 5.08 € )	Stock item: 1 working dayAvailable for same-day shipping
3.40 € ( 4.05 € )	5 working days
4.03 € ( 4.80 € )	5 working days
11.32 € ( 13.47 € )	5 working days
9.80 € ( 11.66 € )	5 working days
8.48 € ( 10.09 € )	5 working days
9.80 € ( 11.66 € )	5 working days
10.91 € ( 12.98 € )	5 working days
8.89 € ( 10.58 € )	5 working days
13.23 € ( 15.74 € )	5 working days
10.67 € ( 12.70 € )	5 working days
9.17 € ( 10.91 € )	5 working days
7.85 € ( 9.34 € )	5 working days
9.17 € ( 10.91 € )	5 working days
10.28 € ( 12.23 € )	5 working days
8.26 € ( 9.83 € )	5 working days
12.59 € ( 14.98 € )	5 working days
4.91 € ( 5.84 € )	5 working days
12.20 € ( 14.52 € )	5 working days
10.67 € ( 12.70 € )	5 working days
9.36 € ( 11.14 € )	5 working days
10.67 € ( 12.70 € )	5 working days
11.79 € ( 14.03 € )	5 working days
9.77 € ( 11.63 € )	5 working days
14.11 € ( 16.79 € )	5 working days
11.56 € ( 13.76 € )	5 working days
10.04 € ( 11.95 € )	5 working days
8.74 € ( 10.40 € )	5 working days
10.04 € ( 11.95 € )	5 working days
11.17 € ( 13.29 € )	5 working days
9.15 € ( 10.89 € )	5 working days
13.47 € ( 16.03 € )	5 working days

Basic information

A bracket for 2-row grooves with ribs and 4 mounting holes on 1 side. You can connect the frame more firmly.

Technical information

Outline and specifications

Example of Use

Catalog

Products homepage

Catalog (2-page spread)
