Roller Bearings CCC4W33 Series
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| 22228 CCC4W33 |
| 23120 CCC4W33 |
| 23232 CCC4W33 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | I.D. d (mm) | O.D. D (mm) | Width B (mm) | EAN | Weight (g) | |
|---|---|---|---|---|---|---|---|---|---|
841.52 € | 1 | 4 Days | 140 | 250 | 68 | 7316576653049 | 13920.0 | ||
374.15 € | 1 | 4 Days | 100 | 165 | 52 | 7316576638701 | 4365.0 | ||
1,748.50 € | 1 | 4 Days | 160 | 290 | 104 | 7316570667370 | 28720.0 |
Loading...
Basic information
| Inner/Outer Ring Material | Steel | Precision (JIS) | Grade 0 | Rolling Element Material | Steel |
|---|---|---|---|---|---|
| Bore | Cylindrical | Cage | Sheet steel cage | Clearance | Strongly increased radial clearance |
| Outer ring | Lubrication groove with lubrication holes on outer ring | Seal | None. open bearing | Temperature range | -30 to +200 °C |
| Version | Standard version |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
