PARKER Parkrimp No-Skive Fitting 1B448
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| 1B448-4-4 |
| 1B448-6-6 |
| 1B448-8-8 |
| 1B448-12-12 |
| 1B448-16-16 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Nominal Dia. (mm) | A (mm) | Customs tariff weight (kg) | Thread or tube size | W | H (mm) | B (mm) | Operating pressure Mpa | Hose fitting size | Thread diameter BSP | E (mm) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
55.38 € | 1 | 5 Days | 6 | 58 | 0.121 | -04 | 19 | 17 | 34 | 35 | -04 | 1/4x19 | 22 | ||
54.12 € | 1 | 5 Days | 10 | 68 | 0.173 | -06 | 22 | 19 | 45 | 35 | -06 | 3/8x19 | 23 | ||
80.11 € | 1 | 5 Days | 12 | 67 | 0.256 | -08 | 27 | 22 | 43 | 35 | -08 | 1/2x14 | 27 | ||
162.25 € | 1 | 5 Days | 19 | 72 | 0.499 | -12 | 32 | 32 | 47 | 35 | -12 | 3/4x14 | 33 | ||
242.05 € | 1 | 5 Days | 25 | 82 | 0.67 | -16 | 41 | 36 | 52 | 28 | -16 | 1x11 | 34 |
Loading...
Basic information
| Customs tariff weight unit | kg | Steel | Galvanized steel, Cr(VI)-free | Connection group | BSP |
|---|---|---|---|---|---|
| Norm | BS 5200-E | Common name | DKR 90° | Description of connection type | Sealing head with BSP union nut - 90° compact elbow |
| Connection type | B4 | Fitting series | 48 | Customs tariff item number | 73269098 |
| Customs tariff weight per | 1 | Fitting | Parkrimp fitting | Customs tariff country of origin | DE |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
