Radial insert ball bearings / single row / KRR / eccentric locking collar / INA
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| 0008036930000 |
| 0008039280000 |
| 0008049750000 |
| 0008426050000 |
| Part Number | Related to |
Standard Unit Price
| Minimum order quantity | Volume Discount | Inner Diameter d (φ) | Outer Diameter D (φ) | Width B (or T) (mm) | Basic Dynamic Load Rating (N) | Basic Load Rating Static Rating (N) | Shoulder dimension d3 (mm) | C2 (mm) | Shoulder dimension d1 (mm) | Threaded pin width across flats | Width C (mm) | Width with mounting components B1 (mm) | Central length S (mm) | Shoulder dimension D1 (mm) | Customs tariff — weight (kg) | Product code | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
92.54 € | 1 | 5 Days | 60 | 110 | 61.9 | 56000 | 36000 | 96 | 32 | 85.2 | 6 | 28 | 77.9 | 21.5 | 109 | 1.82 | E60-XL-KRR | |||
52.86 € | 1 | 5 Days | 50 | 90 | 49.2 | 37500 | 23200 | 69 | 26.4 | 62.8 | 5 | 22 | 62.8 | 24.6 | 77.3 | 1 | E50-XL-KRR | |||
29.38 € | 1 | 5 Days | 30 | 62 | 36.5 | 20700 | 11300 | 44 | 20.7 | 40.2 | 4 | 18 | 48.5 | 18.3 | 52 | 0.4 | E30-XL-KRR | |||
| - | 24.00 € | 1 | 5 Days | 25 | 52 | 34.9 | 14000 | 7800 | 37.5 | 16.7 | 33.8 | 3 | 15 | 44.5 | 17.5 | 42.5 | 0.25 | E25-XL-KRR |
Loading...
Basic information
| Load Direction | Radial | Size Standard | Metric System | Product type | Radial insert ball bearing |
|---|---|---|---|---|---|
| Ring nut | No | Bore shape | Cylindrical | Designator cover / seal | Two zinc-plated sheet steel washers angled outwards with NBR component between and radially preloaded sealing lip |
| Method of attachment | Eccentric locking collar | Marking cover / seal | KRR | Rotation direction | Constant |
| Model series | E.. | Outer surface design | Cylindrical | Engineering material | Steel |
| Customs tariff — weight per | 1 | Customs tariff — weight unit | kg | Customs tariff — item number | 84821090 |
| Customs tariff — country of origin | DE |
Configure
Basic Attributes
-
Inner Diameter d(φ)
-
Outer Diameter D(φ)
-
Width B (or T)(mm)
-
Basic Dynamic Load Rating(N)
-
Shoulder dimension d3(mm)
-
C2(mm)
-
Shoulder dimension d1(mm)
-
Threaded pin width across flats
-
Width C(mm)
-
Width with mounting components B1(mm)
-
Central length S(mm)
-
Shoulder dimension D1(mm)
-
Customs tariff — weight(kg)
-
Type
-
Filter by CAD data type
- 3D
Filter by standard shipping days
-
- All
- 5 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
