Aluminium Filter / Regulator
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| B38-200-B1KA |
| B38-200-B2KA |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Port Size | |
|---|---|---|---|---|---|
365.07 € | 1 | 5 Days | 1/4" PTF | ||
365.07 € | 1 | 5 Days | 1/4" NPT |
Loading...
Basic information
| Outlet Pressure Adjustment Range(Bar) | 0.25 - 7 | Bonnet | Aluminium | Range | B38 |
|---|---|---|---|---|---|
| Operating Temperature Range(°C) | -40 - 80 | Maximum Inlet Pressure(psi) | 290 | Flow(scfm) | 17 |
| Filter Element | Sintered polypropylene | Body | Aluminium | Flow(dm3/(s.bar)) | 8 |
| Bowl | Aluminium | Maximum Inlet Pressure(Bar) | 31 | Operating Temperature Range(Fahrenheit) | -40 - 175 |
| Elastomers | Nitrile rubber |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
