Handwheels disc aluminium, without cylinder grip, polished (K0161)

Configure

Outside diameter(Ø)
- 80
- 100
- 125
- 140
- 160
- 200
- 250
Height(mm)
- 31
- 34
- 37
- 40
- 46
- 49
B3(mm)
- 3
- 4
- 5
- 6
- 8
D2=Fastening hole(mm)
- 10H7
- 12H7
- 14H7
- 15H7
- 16H7
- 18H7
- 20H7
- 22H7
- 24H7
D3(mm)
- 26
- 30
- 31
- 34
- 40
- 50
L1(mm)
- 16
- 17
- 18
- 19
- 20
- 24
- 28
T(mm)
- 11.4
- 13.8
- 16.3
- 17.3
- 18.3
- 20.8
- 22.8
- 24.8
- 27.3
Type
CAD
- 2D
- 3D
Est. shipping days
- All
- Within 4 working days

Handwheels disc aluminium, without cylinder grip, polished (K0161)

Catalog

Part number:

Still undefined. 28 possible part numbers found.

Part number list
More Information
Catalog

Part number list

Number of items

Part number

Outside diameter

(Ø)

Height

(mm)

D2=Fastening hole

(mm)

Minimum order quantity

80	31	-	10H7	26	16	-	1 pieces
80	31	-	12H7	26	16	-	1 pieces
100	34	-	10H7	31	17	-	1 pieces
100	34	-	12H7	31	17	-	1 pieces
125	37	-	12H7	30	18	-	1 pieces
125	37	-	14H7	30	18	-	1 pieces
140	34	-	14H7	34	19	-	1 pieces
140	34	-	15H7	34	19	-	1 pieces
160	40	-	15H7	40	20	-	1 pieces
160	40	-	16H7	40	20	-	1 pieces
200	46	-	18H7	50	24	-	1 pieces
200	46	-	20H7	50	24	-	1 pieces
250	49	-	22H7	50	28	-	1 pieces
250	49	-	24H7	50	28	-	1 pieces
80	31	3	10H7	26	16	11.4	1 pieces
80	31	4	12H7	26	16	13.8	1 pieces
100	34	3	10H7	31	17	11.4	1 pieces
100	34	4	12H7	31	17	13.8	1 pieces
125	37	4	12H7	30	18	13.8	1 pieces
125	37	5	14H7	30	18	16.3	1 pieces
140	34	5	14H7	34	19	16.3	1 pieces
140	34	5	15H7	34	19	17.3	1 pieces
160	40	5	15H7	40	20	17.3	1 pieces
160	40	5	16H7	40	20	18.3	1 pieces
200	46	6	18H7	50	24	20.8	1 pieces
200	46	6	20H7	50	24	22.8	1 pieces
250	49	6	22H7	50	28	24.8	1 pieces
250	49	8	24H7	50	28	27.3	1 pieces

Unit price (excluding VAT)(Unit price including VAT)	Standard shipping days

9.67 € ( 11.51 € )	4 working days
9.67 € ( 11.51 € )	4 working days
11.34 € ( 13.49 € )	4 working days
11.34 € ( 13.49 € )	4 working days
14.56 € ( 17.33 € )	4 working days
14.56 € ( 17.33 € )	4 working days
17.00 € ( 20.23 € )	4 working days
17.00 € ( 20.23 € )	4 working days
23.37 € ( 27.81 € )	4 working days
23.37 € ( 27.81 € )	4 working days
29.85 € ( 35.52 € )	4 working days
29.85 € ( 35.52 € )	4 working days
53.52 € ( 63.69 € )	4 working days
53.52 € ( 63.69 € )	4 working days
11.40 € ( 13.57 € )	4 working days
11.40 € ( 13.57 € )	4 working days
13.14 € ( 15.64 € )	4 working days
13.14 € ( 15.64 € )	4 working days
16.45 € ( 19.58 € )	4 working days
16.45 € ( 19.58 € )	4 working days
18.88 € ( 22.47 € )	4 working days
18.88 € ( 22.47 € )	4 working days
25.29 € ( 30.10 € )	4 working days
25.29 € ( 30.10 € )	4 working days
31.90 € ( 37.96 € )	4 working days
31.90 € ( 37.96 € )	4 working days
56.14 € ( 66.81 € )	4 working days
56.14 € ( 66.81 € )	4 working days

More Information

Basic information

Basic information

· Control element for positioning and adjusting shafts and spindles

· Application sectors: machine, plant, armament and instrument construction, measuring equipment

· For opening, closing and operating valves in fittings, machine tools

· Wheel rim concentricity and axial run-out less than ISO tolerance (IT) 12

Catalog

Products homepage

Catalog (2-page spread)
