Configure
- Mounting Height H(mm)
- 255
- 280
- 305
- 358
- 380
- 430
- Plate Length L(mm)
- 140
- 175
- 255
- 400
- Plate Width W(mm)
- 110
- 140
- 200
- 300
- Wheel Dia. D(mm)
- 200
- 250
- 300
- 306
- Wheel Width B(mm)
- 55
- 65
- 80
- 85
- 90
- 105
- Total height(mm)
- 145
- 170
- 205
- 255
- 280
- 380
- 430
- Weight(g)
- 3821
- 4000
- 6330
- 6780
- 10150
- 11017
- 16400
- 17718
- 28800
- 31035
- 63540
- 87730
- Wheel diameter(mm)
- 100
- 125
- 150
- 200
- 250
- 300
- Wheel width(mm)
- 40
- 55
- 65
- 80
- 90
- Load capacity at 4 km/h(kg)
- 1700
- 1750
- 3000
- 6000
- 10000
- 12000
- Type
- Est. shipping days
- All
- Within 5 working days
- Within 7 working days
- Within 23 working days
Heavy Duty Welded Steel Fixed Castor, BS-SVS Series
Part number:
possible part numbers found.Part number list
Number of items
| Part number |
|---|
Unit price (excluding VAT)(Unit price including VAT) | Standard shipping days |
|---|
194.55 € ( 231.51 € ) | 5 working days |
256.82 € ( 305.62 € ) | 23 working days |
248.33 € ( 295.51 € ) | 5 working days |
313.05 € ( 372.53 € ) | 23 working days |
499.89 € ( 594.87 € ) | 5 working days |
572.90 € ( 681.75 € ) | 23 working days |
1,082.28 € ( 1,287.91 € ) | 7 working days |
1,322.41 € ( 1,573.67 € ) | 23 working days |
697.95 € ( 830.56 € ) | 7 working days |
789.09 € ( 939.02 € ) | 23 working days |
3,049.86 € ( 3,629.33 € ) | 23 working days |
4,743.60 € ( 5,644.88 € ) | 23 working days |
More Information
Basic information
Heavy Duty Welded Steel Fixed Castor, Extra Heavy Duty Solid Steel Wheel
Bracket: BS series
- particularly robust welded steel construction
- zinc-plated, yellow-passivated, Cr6-free
Wheel: SVS series
- heat-treatable steel, hardness 190–230 HB, slightly crowned tread
- chemical resistance to many aggressive substances
- operating temperature: -20 °C to +120 °C
- consider the surface pressure on sensitive floors due to high point loads
