Cylindrical straight bolts, Form B (02020)
· Toleranced dimension for exact positioning
· Suitable as feet for fixtures
· Hardened and ground
· Support faces without centrebore
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| 02020-206 |
| 02020-208 |
| 02020-210 |
| 02020-212 |
| 02020-216 |
| 02020-220 |
| 02020-225 |
| 02020-306 |
| 02020-308 |
| 02020-310 |
| 02020-312 |
| 02020-316 |
| 02020-320 |
| 02020-325 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Pin diameter (mm) | Version 1 | D1=Outside diameter (mm) | H=Height (mm) | H1 (mm) | H2 (mm) | H3 (mm) | T (mm) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
8.85 € | 1 | 4 Days | 4 | Short | 6 | 7 | 6 | 1.2 | 4 | 0.02 | ||
9.15 € | 1 | 4 Days | 6 | Short | 8 | 10 | 9 | 1.6 | 6 | 0.02 | ||
9.45 € | 1 | 4 Days | 6 | Short | 10 | 10 | 9 | 1.6 | 6 | 0.02 | ||
10.20 € | 1 | 4 Days | 6 | Short | 12 | 10 | 9 | 1.6 | 6 | 0.02 | ||
12.09 € | 1 | 4 Days | 8 | Short | 16 | 13 | 12 | 2 | 8 | 0.04 | ||
15.36 € | 1 | 4 Days | 12 | Short | 20 | 15 | 18 | 2 | 9 | 0.04 | ||
16.63 € | 1 | 4 Days | 12 | Short | 25 | 15 | 18 | 2.5 | 9 | 0.04 | ||
8.93 € | 1 | 4 Days | 4 | Long | 6 | 12 | 6 | 1.2 | 4 | 0.02 | ||
9.30 € | 1 | 4 Days | 6 | Long | 8 | 16 | 9 | 1.6 | 6 | 0.02 | ||
9.72 € | 1 | 4 Days | 6 | Long | 10 | 18 | 9 | 1.6 | 6 | 0.02 | ||
10.53 € | 1 | 4 Days | 6 | Long | 12 | 18 | 9 | 1.6 | 6 | 0.02 | ||
12.21 € | 1 | 4 Days | 8 | Long | 16 | 22 | 12 | 2 | 8 | 0.04 | ||
16.04 € | 1 | 4 Days | 12 | Long | 20 | 25 | 18 | 2 | 9 | 0.04 | ||
18.48 € | 1 | 4 Days | 12 | Long | 25 | 25 | 18 | 2.5 | 9 | 0.04 |
Loading...
Basic information
| Type (Basic Shape) | Large Head | Material | Steel | Main material | Tool steel |
|---|---|---|---|---|---|
| Surface finish body | Hardened and ground | Material (mount surface / support surface) | Steel | Form | B |
