Handwheels 2-spoke, aluminium, flat wheel rim, fixed cylinder grip (06277)
· Application sectors: machine, plant, equipment construction and measuring devices
· For opening, closing and operating valves in fittings, machine tools
· Wheel rim concentricity and axial run-out less than ISO tolerance (IT) 12
· Cylinder grip Duroplast, grip pin galvanised steel, wheel rim polished
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Outside diameter (Ø) | Version 1 | L1 (mm) | L3=height (mm) | D2=Fastening hole (mm) | D3 (mm) | B3 (mm) | Fixed cylinder grip (mm) | T (mm) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
19.14 € | 1 | 4 Days | 80 | Reamed hole | 16 | 28 | 10H7 | 24 | - | Ø18 x M6 x 40 | - | ||
19.14 € | 1 | 4 Days | 80 | Reamed hole | 16 | 28 | 12H7 | 24 | - | Ø18 x M6 x 40 | - | ||
21.78 € | 1 | 4 Days | 100 | Reamed hole | 17 | 33 | 10H7 | 26 | - | Ø18 x M6 x 40 | - | ||
21.78 € | 1 | 4 Days | 100 | Reamed hole | 17 | 33 | 12H7 | 26 | - | Ø18 x M6 x 40 | - | ||
25.46 € | 1 | 4 Days | 125 | Reamed hole | 18 | 33.5 | 12H7 | 31 | - | Ø21 x M8 x 50 | - | ||
25.46 € | 1 | 4 Days | 125 | Reamed hole | 18 | 33.5 | 14H7 | 31 | - | Ø21 x M8 x 50 | - | ||
34.10 € | 1 | 4 Days | 160 | Reamed hole | 20 | 39 | 14H7 | 40 | - | Ø26 x M10 x 80 | - | ||
34.10 € | 1 | 4 Days | 160 | Reamed hole | 20 | 39 | 16H7 | 40 | - | Ø26 x M10 x 80 | - | ||
49.28 € | 1 | 4 Days | 200 | Reamed hole | 24 | 45 | 18H7 | 42 | - | Ø26 x M10 x 80 | - | ||
49.28 € | 1 | 4 Days | 200 | Reamed hole | 24 | 45 | 20H7 | 42 | - | Ø26 x M10 x 80 | - | ||
73.13 € | 1 | 4 Days | 250 | Reamed hole | 28 | 51 | 22H7 | 48 | - | Ø28 x M12 x 90 | - | ||
73.13 € | 1 | 4 Days | 250 | Reamed hole | 28 | 51 | 26H7 | 48 | - | Ø28 x M12 x 90 | - | ||
21.36 € | 1 | 4 Days | 80 | Reamed hole with slot | 16 | 28 | 10H7 | 24 | 3 | Ø18 x M6 x 40 | 11.4 | ||
21.36 € | 1 | 4 Days | 80 | Reamed hole with slot | 16 | 28 | 12H7 | 24 | 4 | Ø18 x M6 x 40 | 13.8 | ||
24.03 € | 1 | 4 Days | 100 | Reamed hole with slot | 17 | 33 | 10H7 | 26 | 3 | Ø18 x M6 x 40 | 11.4 | ||
24.03 € | 1 | 4 Days | 100 | Reamed hole with slot | 17 | 33 | 12H7 | 26 | 4 | Ø18 x M6 x 40 | 13.8 | ||
27.75 € | 1 | 4 Days | 125 | Reamed hole with slot | 18 | 33.5 | 12H7 | 31 | 4 | Ø21 x M8 x 50 | 13.8 | ||
27.75 € | 1 | 4 Days | 125 | Reamed hole with slot | 18 | 33.5 | 14H7 | 31 | 5 | Ø21 x M8 x 50 | 16.3 | ||
36.57 € | 1 | 4 Days | 160 | Reamed hole with slot | 20 | 39 | 14H7 | 40 | 5 | Ø26 x M10 x 80 | 16.3 | ||
36.57 € | 1 | 4 Days | 160 | Reamed hole with slot | 20 | 39 | 16H7 | 40 | 5 | Ø26 x M10 x 80 | 18.3 | ||
51.96 € | 1 | 4 Days | 200 | Reamed hole with slot | 24 | 45 | 18H7 | 42 | 6 | Ø26 x M10 x 80 | 20.8 | ||
51.96 € | 1 | 4 Days | 200 | Reamed hole with slot | 24 | 45 | 20H7 | 42 | 6 | Ø26 x M10 x 80 | 22.8 | ||
76.42 € | 1 | 4 Days | 250 | Reamed hole with slot | 28 | 51 | 22H7 | 48 | 6 | Ø28 x M12 x 90 | 24.8 | ||
76.42 € | 1 | 4 Days | 250 | Reamed hole with slot | 28 | 51 | 26H7 | 48 | 8 | Ø28 x M12 x 90 | 29.3 |
