Clevis joints DIN 71752 (27624)
· Application sectors: machine and vehicle construction, material handling
· Version: right or left-hand thread
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | D2=Thread (M) (mm) | Version 2 | A (mm) | B (mm) | D1 (mm) | D3 (mm) | G (mm) | L1 (mm) | L2 (mm) | L3 (mm) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
2.46 € | 1 | 4 Days | 5 | RH Thread | 10 | 5 | 5 | 9 | 10 | 26 | 20 | 7.5 | ||
3.60 € | 1 | 4 Days | 5 | LH Thread | 10 | 5 | 5 | 9 | 10 | 26 | 20 | 7.5 | ||
2.79 € | 1 | 4 Days | 6 | RH Thread | 12 | 6 | 6 | 10 | 12 | 31 | 24 | 9 | ||
3.74 € | 1 | 4 Days | 6 | LH Thread | 12 | 6 | 6 | 10 | 12 | 31 | 24 | 9 | ||
3.60 € | 1 | 4 Days | 8 | RH Thread | 16 | 8 | 8 | 14 | 16 | 42 | 32 | 12 | ||
3.82 € | 1 | 4 Days | 8 | LH Thread | 16 | 8 | 8 | 14 | 16 | 42 | 32 | 12 | ||
4.06 € | 1 | 4 Days | 8 | RH Thread | 16 | 8 | 8 | 14 | 32 | 58 | 48 | 12 | ||
4.20 € | 1 | 4 Days | 10x1.25 | RH Thread | 20 | 10 | 10 | 18 | 20 | 52 | 40 | 15 | ||
4.79 € | 1 | 4 Days | 10x1.25 | RH Thread | 20 | 10 | 10 | 18 | 40 | 72 | 60 | 15 | ||
4.66 € | 1 | 4 Days | 10 | RH Thread | 20 | 10 | 10 | 18 | 20 | 52 | 40 | 15 | ||
6.86 € | 1 | 4 Days | 10 | LH Thread | 20 | 10 | 10 | 18 | 20 | 52 | 40 | 15 | ||
5.29 € | 1 | 4 Days | 10 | RH Thread | 20 | 10 | 10 | 18 | 40 | 72 | 60 | 15 | ||
6.98 € | 1 | 4 Days | 12x1.25 | RH Thread | 24 | 12 | 12 | 20 | 24 | 62 | 48 | 18 | ||
8.36 € | 1 | 4 Days | 12x1.25 | RH Thread | 24 | 12 | 12 | 20 | 48 | 86 | 72 | 18 | ||
6.73 € | 1 | 4 Days | 12 | RH Thread | 24 | 12 | 12 | 20 | 24 | 62 | 48 | 18 | ||
10.38 € | 1 | 4 Days | 12 | LH Thread | 24 | 12 | 12 | 20 | 24 | 62 | 48 | 18 | ||
7.71 € | 1 | 4 Days | 12 | RH Thread | 24 | 12 | 12 | 20 | 48 | 86 | 72 | 18 | ||
8.87 € | 1 | 4 Days | 14 | RH Thread | 27 | 14 | 14 | 24 | 28 | 72 | 56 | 22.5 | ||
14.52 € | 1 | 4 Days | 16x1.5 | RH Thread | 32 | 16 | 16 | 26 | 32 | 83 | 64 | 24 | ||
13.70 € | 1 | 4 Days | 16 | RH Thread | 32 | 16 | 16 | 26 | 32 | 83 | 64 | 24 | ||
17.97 € | 1 | 4 Days | 16 | LH Thread | 32 | 16 | 16 | 26 | 32 | 83 | 64 | 24 |
Loading...
Basic information
| Material | Steel | Surface finish body | Galvanised |
|---|
Configure
Basic Attributes
-
D2=Thread (M)(mm)
-
Version 2
- LH Thread
- RH Thread
-
A(mm)
-
B(mm)
-
D1(mm)
-
D3(mm)
-
G(mm)
-
L1(mm)
-
L2(mm)
-
L3(mm)
Filter by standard shipping days
-
- All
- 4 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
