Five lobe grips with external thread (06850)

Five lobe grips with external thread (06850)

Part number:

Still undefined. 13 possible part numbers found.
Quantity:

Part number list

Number of items
  • 1
    • Part number
    06850-3206X12
    06850-3206X18
    06850-3208X16
    06850-3208X24
    06850-4006X18
    06850-4008X16
    06850-4008X20
    06850-4008X24
    06850-4010X30
    06850-5008X16
    06850-5008X24
    06850-5010X20
    06850-5010X30

    D

    Length

    (mm)

    Outside diameter

    (φ)

    Main Body Height t

    (mm)

    D3

    (mm)

    H1

    (Nm)

    L=thread length

    (mm)

    		Minimum order quantity
    M6
    12
    32
    22.4
    16
    11.2
    12
    1 pieces
    M6
    18
    32
    22.4
    16
    11.2
    18
    1 pieces
    M8
    16
    32
    22.4
    16
    11.2
    16
    1 pieces
    M8
    24
    32
    22.4
    16
    11.2
    24
    1 pieces
    M6
    18
    40
    28
    20
    14
    18
    1 pieces
    M8
    16
    40
    28
    20
    14
    16
    1 pieces
    M8
    20
    40
    28
    20
    14
    20
    1 pieces
    M8
    24
    40
    28
    20
    14
    24
    1 pieces
    M10
    30
    40
    28
    20
    14
    30
    1 pieces
    M8
    16
    50
    35
    25
    17.5
    16
    1 pieces
    M8
    24
    50
    35
    25
    17.5
    24
    1 pieces
    M10
    20
    50
    35
    25
    17.5
    20
    1 pieces
    M10
    30
    50
    35
    25
    17.5
    30
    1 pieces
    Unit price (excluding VAT)(Unit price including VAT)
    Standard shipping days
    1.57 €
    ( 1.87 € )
    4 working days
    1.57 €
    ( 1.87 € )
    4 working days
    1.57 €
    ( 1.87 € )
    4 working days
    1.57 €
    ( 1.87 € )
    4 working days
    1.82 €
    ( 2.17 € )
    4 working days
    1.82 €
    ( 2.17 € )
    4 working days
    1.82 €
    ( 2.17 € )
    4 working days
    1.82 €
    ( 2.17 € )
    4 working days
    2.28 €
    ( 2.71 € )
    4 working days
    2.59 €
    ( 3.08 € )
    4 working days
    2.59 €
    ( 3.08 € )
    4 working days
    2.59 €
    ( 3.08 € )
    4 working days
    2.59 €
    ( 3.08 € )
    4 working days
  • 1

    • More Information

    Basic information

    · Can be used as a clamping, retaining and fastening element

    · Application fields: machine, plant and fixture construction, toolmaking

    · For manually adjusting assemblies, machines and aggregates

    · Different thread sizes
