    KIPP

    Side clamps, Form B (K1697)

    Side clamps, Form B (K1697)

    Part number:

    Still undefined. 2 possible part numbers found.
    Quantity:

    Part number list

    Number of items
  • 1
    • Part number
    K1697.02001
    K1697.03001

    B=Width

    (mm)

    B1

    (mm)

    B2

    (mm)

    B3

    (mm)

    B4

    (mm)

    D=thread

    (mm)

    D1

    (mm)

    H=Height

    (mm)

    H1

    (mm)

    H2

    (mm)

    H3

    (mm)

    H4

    (mm)

    H5

    (mm)

    L=Length

    (mm)

    L2

    (mm)

    L3

    (mm)

    L4

    (mm)

    L5

    (mm)

    Travel S

    (mm)

    T=thread depth

    (mm)

    Clamping force

    (kN)

    D3

    (mm)

    R

    (mm)

    H6

    (mm)

    Hand force FH

    (N)

    L6

    (mm)

    Weight

    (kg)

    		Minimum order quantity
    75
    60
    45
    15
    30
    M4
    6.6
    32
    27
    18
    18
    18
    8
    51
    48
    20
    13
    3
    1.6
    6
    2
    M4x5
    63
    19
    150
    51.5
    0.6200
    1 pieces
    100
    80
    60
    20
    40
    M5
    8.6
    40
    33
    22
    22
    22
    10
    67
    63
    26
    17
    4
    2.2
    8
    3
    M5x6
    80
    24
    200
    67
    1.3600
    1 pieces
    Unit price (excluding VAT)(Unit price including VAT)
    Standard shipping days
    186.69 €
    ( 222.16 € )
    4 working days
    246.15 €
    ( 292.92 € )
    4 working days
  • 1

    • More Information

    Basic information

    · Ground clamping face

    · Pull-down force prevents the workpiece lifting
